BUMPERS & WINCHES
PART NUMBER:
WR78000 346.90
G
EXTREME TERRAIN
RUGGED TERRAIN
PART NUMBER:
WR78500 433.90
G
EXTREME TERRAIN
RUGGED TERRAIN
Rated Line Pull:
1500 lbs (680 kgs)
Motor:
12V DC, 0.4HP
Permanent Magnet, Sealed
Control:
Handlebar Mounted
Mini-rocker Switch
Gear Train:
3-Stage Planetary
Gear Ratio:
103:1
Clutch (freespooling):
Cam activated
Brake:
Mechanical Brake Standard
Drum Diameter / Length:
1.5” / 3.0”
Fairlead:
Hawse
Rated Line Pull:
1500 lbs (680 kgs)
Motor:
12V DC, 0.4HP
Permanent Magnet, Sealed
Control:
Handlebar Mounted Mini-rocker Switch
Gear Train:
3-Stage Planetary
Gear Ratio:
103:1
Clutch (freespooling):
Cam activated
Brake:
Mechanical Brake Standard
Drum Diameter / Length:
1.5” / 3.0”
Fairlead:
Roller
Wire Rope:
50’ Synthetic, 5/32” diameter
(12.2m, 4mm diam.)
With 1,500 lbs. of pulling power, this winch is great for getting a stuck sport quad or small ATV
out of a sticky situation. Standard features include a sealed 0.4hp motor; 50’ of 5/32” diameter
aircraft-grade wire rope; a potted-and-sealed mini-rocker handlebar control; a compact waterproof
contactor; and a hawse fairlead.
This is the top-of-the-line 1.500 lb. light-duty winch perfect for sport quads or small ATVs. It
comes standard with 50’ of 5/32” synthetic rope for light weight and easy handling; a sealed
0.4hp motor; a potted-and-sealed mini-rocker handlebar control; a compact waterproof
contactor; and a roller fairlead.
EXTREME TERRAIN
RUGGED TERRAIN
Rated Line Pull:
4000 lbs (1814 kgs)
Motor:
12V DC, 1.5 HP (1.1kw)
Permanent Magnet
Control:
Remote Control w/10’ (3m) Lead &
Universal Mount Mini-Rocker
Gear Train:
3-Stage Planetary
Gear Ratio:
136:1
Clutch (freespooling):
Sliding Pin and Ring Gear
Brake:
Roller Disk (patented)
Drum Diameter / Length:
2.0” / 4.7” (52mm / 119mm)
Fairlead:
Roller
Wire Rope:
55’ Aircraft-Grade Wire,
7/32” diameter (16.8m, 5.5mm)
Wire Rope:
50’ Aircraft-Grade Wire, 5/32”
diameter (15m, 4mm diam.)
Recommended Battery:
12 AMP / Hour Minimum
Battery Leads:
10 Gauge
Duty Cycle:
Intermittent
Warranty:
Limited Lifetime
Mounting Bolt Pattern:
3.0” x 4.88” (76 x 124mm)
Winch Dimensions:
10.3” L x 3.0” D x 4.56” H
(26cm L x 10cm D x 11.6cm H)
Winch Weight:
11.5 LBS. (5.2 kgs)
Recommended Battery:
12 AMP / Hour Minimum
Battery Leads:
10 Gauge
Duty Cycle:
Intermittent
Warranty:
Limited Lifetime
Mounting Bolt Pattern:
3.0” x 4.88” (76 x 124mm)
Winch Dimensions:
10.3” L x 3.0” D x 4.56” H (26cm L x 10cm D x 11.6cm H)
Winch Weight:
8.6 LBS. (3.9 kgs)
PART NUMBER:
WR77000 698.00
G
With a whopping 4,000 lbs. of pulling power, this winch is specially designed to pull the extra
weight of a UTV, making it the most powerful winch in the line-up. Features include a potent
1.5 hp motor; 55’ of 7/32” diameter wire rope; a fully sealed drivetrain; an ergonomically
designed clutch knob; a potted-and sealed mini-rocker control with universal mount; a high-
capacity waterproof contactor; and a roller fairlead.
Recommended Battery:
500 CCA Minimum
Battery Leads:
6 Gauge
Duty Cycle:
Intermittent
Warranty:
Limited Lifetime
Mounting Bolt Pattern:
3.0” x 6.66” * (76 x 169mm*)
*FITS WINCH MOUNTS ONLY
Winch Dimensions:
14.42” L x 4.51” D x 4.69” H
(36.6cm L x 11.5cm D x 11.9cm H)
Winch Weight:
13.4 LBS. (6.1 kgs)
SERVICE UPGRADE KITS FOR THE XT30
Wire Rope Assy, 3/16” x 50ft
WR60076 52.10
G
Synthetic Rope kit 3/16”, w/Fairlead
WR72128 123.50
G
Synthetic Rope kit 3/16”
WR73599 83.80
G
Contactor, 12 vdc
WR63070 98.60
G
Remote Control, 10ft lead
WR64849 64.30
G
Socket Assembly, Remote Control
WR69648 41.60
G
Roller Fairlead Kit
WR28929 45.90
G
Plate, Fairlead Mount
WR69901 21.50
G
Hook Kit, 5/16” Clevis w/Strap
WR39557 15.60
G
Strap, Hook
WR69645 4.68
G
Switch Kit, Mini Rocker
WR64851 52.80
G
Mini-Rocker Switch and
a Hand-Held Remote INCLUDED
