2015 ATV / UTV CATALOG
MODEL
YEAR
SWING ARM
BEARING & SEAL
KIT
LINKAGE BEARING
& SEAL KIT
LOWER REAR
SHOCK BEARING
KIT
UPPER REAR
SHOCK BEARING
KIT
ARCTIC CAT
250 2x4
06-09
AB281056 28.95
L
-----
-----
-----
300 2x4
10-12
AB281056 29.44
L
-----
-----
-----
400 DVX
04-08
AB281094 54.15
L
AB271093 78.95
L
AB295025 15.83
L
-----
CAN AM
DS 450 EFI MXC
09
AB281198 50.83
L
AB271173 78.95
L
AB295052 17.97
L
-----
DS 450 EFI MXC
10-12
-----
AB271173 78.95
L
AB295052 17.97
L
-----
DS 450 EFI XXC
09
AB281198 50.83
L
AB271173 78.95
L
AB295052 17.97
L
-----
DS 450 EFI XXC
10-12
-----
AB271173 78.95
L
AB295052 17.97
L
-----
DS 450 STD/X
08-09
AB281198 50.83
L
AB271173 78.95
L
AB295052 17.97
L
-----
DS 450 STD/X
10-14
-----
AB271173 78.95
L
AB295052 17.97
L
-----
Quest 500
02-03
AB281155 29.44
L
-----
-----
-----
Traxter 500
99-05
AB281155 29.44
L
-----
-----
-----
Quest 650
02-04
AB281155 29.44
L
-----
-----
-----
Traxter 650
04-05
AB281155 29.44
L
-----
-----
-----
CANNONDALE
All ATV
01-03
AB281100 51.89
L
-----
-----
-----
GAS GAS
Wild HP 300
03-05
-----
AB271118 78.95
L
-----
-----
Wild HP 450
03-05
-----
AB271118 78.95
L
-----
-----
HONDA
TRX90
93-14
AB281009 51.89
L
-----
-----
-----
ATC200X
83-85
AB281132 49.75
L
-----
-----
-----
ATC200X
86-87
AB281154 49.75
L
-----
-----
-----
TRX200
84
AB281056 29.44
L
-----
-----
-----
TRX200
90-97
AB281010 51.89
L
-----
-----
-----
TRX200D
90-97
AB281010 51.89
L
-----
-----
-----
TRX200SX
86-88
AB281010 51.89
L
-----
-----
-----
ATC250ES
85-87
AB281056 29.44
L
-----
-----
-----
ATV SWINGARM AND LINKAGE BEARING AND SEAL KITS
SWING ARM BEARING KITS
• One kit does it all! All of the bearings, seals, bushings, thrust bearings (if required) in one all inclusive kit in
order to do the job correctly and completely.
• The most comprehensive line of off-road and ATV swing arm kits available anywhere. All bearing shafts
are manufactured with 52100 bearing steel that is hardened and center less ground for a precision fit and
extended wear.
• All steel spacers are case-hardened and plated for resistance to wear and corrosion.
• No more hunting around for missing pieces costing you time and extra money.
• Needle thrust bearings have been replaced with Teflon ® bearings. Designed to live longer in water and dirt.
SWING ARM LINKAGE KITS
• One kit does it all! All of the bearings, seals, shafts, bushings, thrust bearings (if required) in one all inclusive
kit in order to do the job correctly and completely.
• The most comprehensive line of off-road and ATV swing arm linkage kits available anywhere.
• All bearing shafts manufactured with 52100 bearing steel that is hardened and center less ground for a
precision fit and extended wear.
• All steel spacers are case-hardened and plated for resistance to wear and corrosion.
• Linkage kits contain the lower shock bearing components. No more hunting around for missing pieces
costing you time and extra money.
UPPER & LOWER SHOCK BEARING KITS
• Separate kits for upper shock and lower shock (replace only what you need).
• Each All Balls upper and lower shock bearing kit contains the bearing and all of the seals, spacers, and pins
(if required) to rebuild the shock to factory specs.
