ATV REPLACEMENT WHEELS BY CARLISLE
Silver with Red Pin Stripe
• Steel • Painted Silver • One Piece • Locking Bead
DIA. XWIDTH BOLT PATTERN OFFSET IN/OUT TIRE SIZE
PART #
12”
5 on 4.5
CTR
All 12”
16-8582 100.90
B
8” x 8.5”
3 on 100/4 on 130
CTR
21 x 12-8/22 x 11-8
16-8103 45.30
B
12”
5 on 4.5 white
CTR
All 12”
16-9426 100.90
B
LB = Large bell accommodates for oversized brake discs
ATV REPLACEMENT WHEELS BY GBC
These steel wheels fit all the popular ATVs
DIA. XWIDTH OFFSET BOLT PATTERN WEIGHT
PART #
8X8.5 LB 3.5+5
5-130
6.0
GB085130 25.95
AE
9X9 LB
3+6
5-130
8.0
GB095130 42.60
G
10X5 LB 2+3
4-166
8.0
GB104166 38.10
G
WHEEL
SPACER KITS
WIDE TRACS BITE MORE RUT!
BOLT PATTERN
1”
1.5”
ARCTIC CAT
Utility Wide Tracs
4/115
4541151
69.95
B
45411515 79.95
B
BOMBARDIER
Utility Wide Tracs
4/110
---
45411015 79.95
B
HONDA
Utility Wide Tracs
4/110
4541101 69.95
B
45411015 79.95
B
Sport Trac
TRX250EX, TRX300EX,
TRX400EX
4/144
---
45414415 96.95
B
KAWASAKI
Utility Wide Trac
4/137
4/4
4541371
---
80.95
B
45413715
4544150
94.95
82.95
B
B
POLARIS
Utility Wide Trac
4/156 front/rear
4/4 rear only
4541561
---
91.95
B
45415615
4544150
106.95
82.95
B
B
Sport Trac
Scrambler 500
4/156
---
45415615 106.95
B
SUZUKI
Utility Wide Trac
4/110
4541101 69.95
B
45411015 79.95
B
YAMAHA
Utility Wide Trac
4/110
4541101 69.95
B
45411015 79.95
B
Sport Wide Trac
Banshee/Raptor/Warrior
4/156
---
45415615S 106.95
B
POLISHED ALUMINUM ATV WHEELS
OFFSET EXAMPLE
3
+ 5
Offset to the Offset to the
Inside of the Outside of the
Wheel
Wheel
LIMITED TO
PRESENT STOCK
SIZE OFFSET BOLT PATTERN
PART #
10 X 9 LB 3 + 6
4 ON 4
424074 49.50
AD
The Wide Tracs are designed to move ATV wheels slightly out from the
hubs and shocks.
There are several major benefits provided by Wide Tracs:
1)
They extend wheel width for greater stability & increased safety. Riders
of tall ATVs will feel much more comfortable on side hills with the wider
base provided by Wide Tracs.
2)
They provide mud tires a fresh “bite” at the side of ruts
instead of the ATV simply driving down the deepest part of
the center of the ruts where previous riders have been. So the
problem of getting stuck by being “high centered” is reduced.
3)
They allow the installation of larger, aftermarket tires without rubbing
shocks, struts or exhaust systems. Machined from aircraft grade 6061
billet aluminum and use grade 8 studs. No OEM studs are required to
be removed from the ATV and stud extenders are not used. Wide Tracs
bolt to existing studs and the wheel is then bolted to the grade 8 Wide
Trac Stud furnished. Strongest available design and are comparable to
automotive grade wheel adapters.Wide Tracs available in all popular bolt
patterns in 1” and 1.5” widths.
Utility WideTracs
in 4/110 bolt pattern are designed permitting the
installation of wheel center caps, an option that is not provided by any
competitor product.
1) They extend wheel width for greater stability and increased safety,
they provide mud tires a fresh “Bite” at the side of ruts. 2) They reduce
the problem of getting stuck by being “high centered”. 3) They permit
installation of larger tires without rubbing shocks, struts, or exhaust
systems.
Sport Wide Tracs
are designed to move ATV wheels up to an even 1.5”
out from the hubs and effectively extend the width between the tires.
Extended wheel width greatly increases stability and safety at higher
speeds and in off-camber (side hill) situations.
THESE KITSWILL FITTHE FRONT ORTHE REAR AS LONG ASTHE
BOLT PATTERNS ARE THE SAME.
