PLOWS & IMPLEMENTS
THESE ITEMS ARE DROP SHIPPED
FROMTHE MANUFACTURER
PLEASE ALLOW ADDITIONAL
TIME FOR DELIVERY
HEAVY DUTY 3-POINT HITCH SYSTEM
Ready to tear it up? This heavy-duty mainframe is for use on ATV’s and UTV’s and is a Category
“O” 3-point hitch with a 20” drawbar width and 5/8” diameter pins. We added a heavy
duty, 12v electric actuator that does the heavy lifting work for you while also providing
an incredible 300 lbs of downforce - that’s about equal to 10 of those cumbersome
cinder blocks! Unlike tow-behind implements, this available downforce provides strong
ground engagement for better land management and improved food plot success.
The innovative features incorporated into the DirtWorks 3-Point Hitch System provide easy
change over from work to play in just minutes with quick, easy installation and adjustments
without the need for tools.The convenient rocker switch can be mounted to your handle bars so
soil depth adjustments and lift for transport is done without ever having to get off your machine.
With the wide range of implements available for this system, you truly are tricking your UTV
into thinking it’s a tractor!
• 12v electric actuator lift system with 20 amp maximum current draw
• 250 lb lift capacity at the tool bar with 300 lbs down pressure capacity
• 15” vertical lift at the drawbar
• Fully adjustable lift arms and top link for maximum customization for any task
• Fits any 2” automotive style receiver hitch or if you don’t have one … check out our
complete line of heavy duty hitches
• Additional frame support kit may be required, please check out our suspension locks
and frame support kits
• Requires Accessory Tool Bar (sold separately)
WHS03HD 804.99
B
Same great features as our WHS03HD 3-point, now paired with our 48”
Tool Bar specifically for ATV’s. Includes a heavy duty, 12v electric actuator
that does the heavy lifting for you and still provides an incredible 300 lbs of
downforce! Unlike tow-behind implements, this available downforce provides
strong ground engagement for wildlife food plot preparation and other land
maintenance tasks.
• 12v electric actuator lift system with 20 amp maximum current draw
• 250 lb lift capacity at the tool bar with 300 lbs down pressure capacity
• 15” vertical lift at the drawbar
• Fully adjustable lift arms and top link for maximum customization for
any task
• Fits any 2” automotive style receiver hitch or if you don’t have one …
check out our heavy duty line of hitches
• Recommended for use with ATV Suspension Lock
• Recommended for use on ATV’s 350cc or larger
ATV 3-POINT HITCH SYSTEM
W/48” TOOL BAR
Our DirtWorks Accessory Tool Bar is the common mounting platform for all the Kolpin
Dirtworks implements and allows a quick change from one implement to another. Each
of our Dirtworks implements are designed to slide into, or plug into the tool bar for use
with the 3-Point Hitch. Two different sizes are available for ATV and UTV applications.
• 48” Tool Bar for use with ATVs or UTVs
• 60” Tool Bar for use with an UTV
• Heavy-duty, black powder coated tool bar
WHS03HDTB 919.99
B
ACCESSORY TOOL BAR
ATB48
48”WIDTH 126.49
B
ATB60
60”WIDTH
149.49
B
