Make the first name in snowmobile belts your first
choice in ATV belts!
Carlisle is the leader in variable speed belt technology.
Carlisle designs and manufactures the number one selling
snowmobile belts, the same type of belt that powers your ATV.
Choose Hypermax to deliver maximum drive performance.
Cruise with Carlisle!
Cruise with confidence with the industry’s leader. Extensive
research and development assures that every Hypermax belt
provides durable, aggressive operation. For almost a century,
Carlisle has engineered and manufactured products for
industry’s most critical applications.
The Drive Belt of Choice for High Performance!
Each belt is crafted from only the best rubber compounds
and tough Aramax cord. Carlisle belts enhance the efficiency
of the variable speed drive system. Hypermax eliminates
excessive friction and tension preventing drive damage.
Exacting belt length tolerance minimizes system wear and
avoids slippage.
Carlisle ATV Belts are part of the family of high performance
products from Carlisle Power Transmission Products Inc.
CARLISLE HYPERMAX ATV BELTS
PART #
O.C.
TOPWIDTH
UA400
33-5/32"
1-3/16"
UA401
36-27/32"
1-7/16"
UA402
35-3/16"
11/16"
UA403
26-21/32"
11/16"
UA404
43-29/32"
1-3/16"
UA406
36-3/4"
1-29/64"
UA407
33-15/32”
1-1/8”
UA409
39-9/32"
1-1/4"
UA410
40-33/64"
1-9/32"
UA411
42-5/32"
1-3/64"
UA412
41”
1-5/32
UA413
41”
1-5/32
UA415
28-3/8"
11/16"
UA416
33-11/16"
1-11/64"
UA417
34-1/2”
1-13/64”
UA418
33-17/64”
1-1/8”
UA419
38-11/16”
1-5/16”
UA420
37-11/32"
1-19/63"
UA421
29-7/8”
23/32”
UA422
37"
1-19/64"
UA423
37-11/64”
1-17/64”
UA424
41-7/32"
1-3/16"
UA425
36-61/64"
25/32"
UA426
40-57/64
1-10/64”
UA427
43-37/64
1-3/8”
UA429
43-47/64"
1-15/64"
UA435
37-7/64"
1-1/4"
UA436
35-3/16"
43/64"
UA437
37-5/16”
1-7/16”
UA440
43-13/16”
1-3/8”
UA442
42-7/32”
1-17/64”
UA444
36-11/16”
15/16”
UA445
37-10/32”
1-7/16”
UA446
38-3/8”
1-5/16”
PLEASE NOTE:
The belt dimensions provided by Carlisle are for reference only.
These dimensions should not be used to determine product
functionality.
Carlisle belts are built to exacting specifications and inspected
with calibrated equipment at specified tensions to assure strict
dimensional compliance.
Belt dimensions can vary from one maunfacturer to another
based on proprietary design information.
CARLISLE HYPERMAX ATV BELTS HYPERMAX ATV BELT DIMENSIONS
