APPLICATION
CALIPER
SIDE IF
PADS
ARE
HANDED YEAR
FRONT
REAR
STANDARD
PAD /
SHOES
LONG
LIFER PADS
/ GROOVE
BRAKE
SHOES
SV
SERIES
SEVERE
DUTY
PADS
FRONT
ROTOR
STANDARD
PAD /
SHOES
LONG
LIFER PADS
/ GROOVED
BRAKE
SHOES
SV
SERIES
SEVERE
DUTY
PADS
REAR
ROTOR
POLARIS ATV
CONTINUED
800SportsmanTouring/EFI
08-09
FA159X FA159R FA159SV 162457 FA159X FA159R FA159SV 162520
800SportsmanBigBoss/EFI6x6/EFI
09-14
FA159X FA159R FA159SV 162457
-----
FA314R FA314SV 162520
850SportsmanTouringEPS
10-13
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850SportsmanTouringH.O.EPS
13-14
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850SportsmanForest
12
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850XPH.O.Scrambler
13-14
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850XPSportsman
09-13
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850XPEPSSportsman
09-13
FA475X FA475R -----
162552 FA475X FA475R -----
162552
850XPH.O.EPSSportsman
13-14
FA475X FA475R -----
162552 FA475X FA475R -----
162552
¨NOTE:Plain edged rotor will not allow fitment of optional speedo pick up.
(*1)= Note 3 Sets Required
POLARIS RANGER SIDE X SIDE MODELS
PPS/PTV4x4/Series10
FA159X FA159R FA159SV 162457
-----
FA314R FA314SV 162455
PPS/PTV6x6/Series10
FA159X FA159R FA159SV 163114
-----
FA313R FA313SV 162455
PPS/UTV2x4Series10
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
PPS/UTV4x6Series10
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
1500PPS/UTV2x4Series11
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
PPSLUH6x6
02
FA159X FA159R FA159SV 163114
-----
FA313R FA313SV 162442
PPS/Series112x4/4x4
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
PPS/Series116x6
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
RangerSeries10
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
Ranger2x4/4x4
04-05
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
RangerSeries11
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
Ranger6x6
04-05
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
RangerTM
04-05
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
RangerTM
06
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
RangerXP
05
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
500RangerSeries106x6
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162456
Ranger(Note:MiddlebrakeN/A)
99
FA159X FA159R FA159SV 163114
-----
FA273R -----
-----
400Ranger(AllModels)
10-14
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
500Ranger(2x4/4x4)
06-07
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
500Ranger(4x4EFi)
06-07
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
500Ranger(4x4EFi)
08-10
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
500Ranger(4x4EFi)
11-13
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
500Ranger(Carb)2x4
08-09
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
500Ranger(EFi)4x4H.O.
09-11
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
500RangerCrew
11-13
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
550SportsmanX2
10
FA475X FA475R
162552 FA475X FA475R -----
162552
570RangerEFi
14
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
570RangerCrewEFi
14
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
700Ranger6x6EFi
06-09
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
700RangerXP4x4
06
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
700Ranger4x4EFi/LE
07
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
700Ranger4x4EFi
09
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
700RangerCrew(EFi)4x4
09
164040
FA452R 164055 162457 164040
FA452R 164055 162520
700Ranger6x4EFi
08
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
700RangerXP4x4
08
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
RangerEV(Electric)
10-14
164040
FA452R 164055 162457
-----
FA354R FA354SV 162520
800Ranger
10-12
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
800RangerEFi
13-14
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
800RangerMidSize
13-14
-----
FA354R FA354SV 162457
-----
FA354R FA354SV 162520
800RangerXP
10-12
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
800Ranger6X6
10-14
164040
FA452R 164055 162312 164040
FA452R 164055 162520
800RangerCrew
10-14
164040
FA452R 164055 162312 164040
FA452R FA354SV 162520
900RangerCrew
10-14
164040
FA452R 164055 162312 164040
FA452R FA354SV 162520
900DCrewRangerDiesel
13-14
164040
FA452R 164055 162312 164040
FA452R 164055 162520
900DRangerDiesel
11-14
164040
FA452R 164055 162312
-----
FA354R FA354SV 162520
900(RangerXP900)
13-14
164040
FA452R 164055 162312
-----
FA354R FA354SV 164063
