2015 MARINE CATALOG
MARINE
towing &
loading
MODEL
YEARS
BORE
X
STROKE
(MM)
DISPL.
(CC)
BORE
SIZE
(MM)
OVER
SIZES
(MM)
COMPLETE
REPAIR KIT
(PISTONS,
RINGS,
CLIPS,PINS
& GASKETS)
WISECO
PISTON
PART #
REPL
RING SET
PART #
REPL
PIN &
CLIPS
TOP END
GASKET KIT
TOP END
BEARING
ARCTIC CAT
650cc Twin Cylinder
76 639 76.00 0.31
102280 102449 2992TD S461 101556
B1024
Barracuda 640
94-95 X 652 76.50 0.81
102281 102450 3012TD
Daytona 640
93-95 71 661 77.00 1.31
102282 102451 3032TD CW20
Monte Carlo 640
94-97
Montego 640
94-97
Montego Deluxe 640
94-97
Tigershark 640
93
TS 640
98-99
TSL 640
98
Note: *0.31 not standard
*Replacement must be bored
*Kit includes pistons, rings,
retainer clips, pins, and gasket
900cc Triple Cylinder
76.5 896 76.50 STD
102951 2349M07650 3012TDW S512 103411
B1024
Monte Carlo 900
96
X 998 80.50 4.00
-----
2349M08050 3169TD
Tigershark 900
95 65
CW20
*Nikasil Bore - Cylinder sleeving
required for 76.5 & 80.5mm bore
*Kit includes pistons, rings,
retainer clips, pins, and gasket
1000cc Triple Cylinder
81 1000 81.00 STD
103083 2394M08100 3189KD S539 103411
Daytona 1000 1997
97
X 1100 85.00 4.00
103081 718M08500 3347KD
Monte Carlo 1000 1997
97 64.6
CW22
*Nikasil Bore - Cylinder sleeving
required for 85mm bore
*Kit includes pistons, rings,
retainer clips, pins, and gasket
KAWASAKI
300cc Single Cylinder
76 295 76.00 STD
101898 102347
-----
S513 100866
B1022
300 SX
87-91 X 299 76.50 0.50
101899 102348 3012TD
JS300
86-88 64.9 303 77.00 1.00
101900 102349 3032TD CW18
307 77.50 1.50
102947 103423 3051TD
311 78.00 2.00
102948 103424 3071TD
440cc Twin Cylinder
68 436 68.25 0.25
-----
-----
2687CD S259 102976
B1021
JS440
76-92 X 439 68.50 0.50
101553
-----
2697CD
60 442 69.00 1.00
101554
-----
2717CD CW16
449 69.50 1.50
102163
-----
2736CD
455 70.00 2.00
-----
-----
2756CD
475cc Big Bore Kit Twin Cylinder
71 475 71.00 STD
-----
102086 2795CD S259 W5294
JS440
76-92 X 481 71.50 0.50
102892 102087 2815CD
60 488 72.00 1.00
102893 102088 2835CD CW16
496 72.50 1.50
-----
101350 2854CD
502 73.00 2.00
103088 101351 2874CD
550cc Twin Cylinder
75 531 75.00 STD
103539 101240 104493 S259 101868
B1021
550 SX
89-91 X 537 75.50 0.50
103540 101241 104495
JS550
82-88 60 544 76.00 1.00
103541 101242 2992TC CW16
551 76.50 1.50
101970 100661 3012TC
559 77.00 2.00
101971 100662 3032TC
PERSONAL WATERCRAFT
PISTONS AND GASKET SETS
SEE PAGES 252-253 FORWISECO PISTON PRICING
