WSM INTAKE GASKETS continued
SEA-DOO
FIG. 1
SEA-DOO
FIG. 2
MAKE/MODEL YEAR CARBURETOR DESCRIPTION
OEM #
QTY PART #
FIG REF
KAWASAKI
CONTINUED
1100 STX DI
00-03
REED VALVE GASKET
11060-3717 3
326944 2.25
L 1 1
1100 ULTRA 130 DI 01-04
REED VALVE GASKET
11060-3757 3
326704 4.40
L 1 2
1200 STX-R
02-05 KEIHIN 38mm CARB GASKET
11060-3776 3
326731 3.00
L
1200 ULTRA 150 99-05 TRIPLE CARB
REED VALVE GASKET
11060-3717 3
326944 2.25
L 1 1
REED VALVE GASKET
11060-3757 3
326704 4.40
L 1 2
POLARIS
650/750
CARB GASKET
3240128
3
326857 1.05
L
REED VALVE GASKET
3084148
6
326919 1.25
L
FLAME ARRESTOR
5830013
3
326920 1.20
L
700
CARB GASKET
5830043
2
326850 2.80
L
FLAME ARRESTOR
5830062
2
326849 1.50
L
780
CARB GASKET
3240128
3
326857 1.05
L
REED VALVE GASKET
3084148
9
326919 1.25
L
FLAME ARRESTOR
5830013
3
326920 1.20
L
800
CARB GASKET
5830043
2
326850 2.80
L
UPPER CARB GASKET
5830062
2
326849 1.50
L
900-1050
CARB GASKET
5830043
3
326850 2.80
L
FLAME ARRESTOR
5830062
3
326849 1.50
L
1200
CARB GASKET
5830043
3
326850 2.80
L
SEA-DOO
580
90-91 MIKUNI 38mm CARB GASKET
290-850-372 1
326857 1.05
L 1 1
580 GTS
92-96 SINGLE CARB
ROTORY COVER FRONT O-RING 290-850-160 1
327197 2.35
L 1 2
580 SP
95
ROTORY COVER REAR O-RING 293-300-023 1
327202 3.35
L 1 3
580 SPi
95-96
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
580 XP
91-92
580 GTX
92-93 MIKUNI 38mm CARB GASKET
290-850-373 1
326857 1.05
L 1 1
580 SP
91-94 SINGLE CARB
ROTORY COVER FRONT O-RING 290-831-705 1
327200 3.30
L 1 2
580 SPi
93-94
ROTORY COVER REAR O-RING 293-300-023 1
327202 3.35
L 1 3
580/650 SPX
93
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
650 XP
93-94
650 GTX
95 MIKUNI 38mm CARB GASKET
290-850-373 2
326857 1.05
L 1 1
DUAL CARB
ROTORY COVER FRONT O-RING 290-931-440 1
327198 4.25
L 1 2
ROTORY COVER REAR O-RING 290-300-023 1
327202 3.35
L 1 3
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
650 SPX
95
CARB GASKET
270-000-114 2
326958 1.45
L 1 1
720 Gti/HX/SPX/XP 95-96 MIKUNI 39mm ROTORY COVER FRONT O-RING 290-931-440 1
327198 4.25
L 1 2
DUAL CARB
ROTORY COVER REAR O-RING 290-300-023 1
327202 3.35
L 1 3
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
650 XPi
94 MIKUNI 39mm CARB GASKET
270-000-114 2
326958 1.45
L 1 1
DUAL CARB
ROTORY COVER FRONT O-RING 290-831-705 1
327200 3.30
L 1 2
ROTORY COVER REAR O-RING 293-300-023 1
327202 3.35
L 1 3
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
720 GS/GSi/GTS/GTi 97-98 MIKUNI 39mm CARB GASKET
293-250-070 2
326958 1.45
L 1 1
SINGLE CARB
ROTORY COVER FRONT O-RING 290-850-160 1
327197 2.35
L 1 2
ROTORY COVER REAR O-RING 293-300-023 1
327202 3.35
L 1 3
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
720 SP
97 MIKUNI
CARB GASKET
290-850-373 2
326857 1.05
L 1 1
SINGLE CARB
ROTORY COVER FRONT O-RING 290-850-160 1
327197 2.35
L 1 2
ROTORY COVER REAR O-RING 293-300-023 1
327202 3.35
L 1 3
OIL INJECTION O-RING
293-300-018 1
327162 0.70
P 1 4
