How the Rev2™Throttle Works
The Rev2™ throttle has several different size reels that
will change how much twist is necessary for the throttle to
completely open the carbs or throttle bodies on a motorcycle.
The larger the reel is, the shorter the twist. Each reel size will
shorten the twist by about 10 degrees. If your stock throttle has a 40mm reel and stock twist is 90 degrees (1/4 turn), the 45mm reel will reduce the
twist to 80 degrees and the 50mm reel will reduce it to 70 degrees. The 35mm reel will increase the throttle twist to approximately 100 degrees.
This is just an example; every model of motorcycle is different.
The included cam reel has a progressive profile that allows the throttle to act like a sensitive, long twist throttle during the initial small throttle
openings for precise control and then acts like a more aggressive short twist throttle at large throttle openings, progressively shortening the amount
of twist needed to reach full throttle.
The most advanced variable rate throttle in the world
• The second generation of our innovative reel changing system lets you tailor the throttle rate to riding conditions and rider preference
• New ultra compact housing with snap-together elbows make it easy to install and change reels
• Sleek new design requires less handlebar space for lever clearance and throttle position
• Use smaller reels for slower throttle rate and larger reels for faster throttle rate
• Included cam reel provides progressive throttle response preferred by some riders
• Unique reel design allows fast reel changes
• Cable boot keeps dirt and dust out for reliable and smooth operation
• Billet aluminum in-line cable adjusters for easy installation and adjustment
• Lower section of cables use 5 mm housing with PTFE liner for reduced friction, increased routing flexibility and lighter weight
• Upper section of cables use 6 mm housing to provide solid support of adjusters
• Simple to install and maintain
• Designed by Motion Pro
• Patent pending
Kits Include
• Complete Rev2™ Throttle Assembly with throttle tube (MX/Off-road kits Include Titan™ Throttle Tube)
• High quality Motion Pro black vinyl cables (specifically designed for your bike)
• 5 interchangeable reels: 35, 40, 45, 50mm and cam reel (Street/Road: orange or MX/Off-Road: gray)
• Set of Motion Pro Grips (Street/Road Race kit: RoadControl™ grips, MX/Off-road kit: DirtControl™ grips)
• Rev2™ Throttle Equipped decal set
• Printed color instructions
REV2 THROTTLE KITS
APPLICAITON
CC TYPE CARB/TB FN YEAR PART #
HONDA
CRF250R
0250 Offroad Stock 142 04-09
682068 164.99
H
CRF250R
0250 Offroad Stock 142 10-13
682069 164.99
H
CRF250R
0250 Offroad Stock 142 14-15
682070 164.99
H
CRF250X
0250 Offroad Stock 142 04-09
682068 164.99
H
CRF250X
0250 Offroad Stock 142 12-13
682068 164.99
H
CRF450R
0450 Offroad Stock 142 02-08
682068 164.99
H
CRF450R
0450 Offroad Stock 142 09-14
682071 164.99
H
CRF450X
0450 Offroad Stock 142 05-09
682068 164.99
H
CRF450X
0450 Offroad Stock 142 12-13
682068 164.99
H
KAWASAKI
KX 250F
0250 Offorad Stock
06-10
682072 164.99
H
KX 250F
0250 Offorad Stock
11-12
682073 164.99
H
KX 250F
0250 Offorad Stock
13-15
682074 164.99
H
KLX 450A / KLX 450R
0450 Offroad Stock
08-09
682072 164.99
H
