LOCKS & PINS
185
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
2015 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
BUYERS COUPLER SAFETY PINS
Buyers coupler pins are available in bulk or in display packages. The display packages are packed two per package
available square loop only. Yellow zinc plated.
A
B
C
D
DIA USABLE
LOOP
PIN
PART #
MFG #
WIDTH LENGTH CLEARANCE LENGTH STYLE
UM
BY6050
66050
1/4”
1-13/16”
1-1/2”
2”
SQUARE EA
0.90
J
BY6063
66063
1/4”
2-1/2”
2-1/2”
2-49/64”
SQUARE EA
1.00
J
BY6064
66064
1/4”
2-1/2”
2-1/2”
2-49/64”
SQUARE PKG 2
2.10
J
BY6066
66066
1/4”
3”
1-1/2”
3-1/4”
SQUARE EA
1.00
J
BY6067
66067
1/4”
3”
1-1/2”
3-1/4”
SQUARE PKG 2
2.10
J
BY6070
66070
1/4
3-5/8”
1-1/2”
3-3/4”
SQUARE EA
1.00
J
BY6053
66053
5/16”
1-5/8”
2-19/32”
2-25/32”
SQUARE EA
0.90
J
BY6054
66054
5/16”
1-5/8”
2-19/32”
2-25/32”
SQUARE PKG 2
1.95
H
BY6056
66056
3/8”
1-17/32”
1-17/32”
1-5/8”
SQUARE EA
1.00
J
BY6060
66060
3/8”
2-11/32”
2-11/32”
2-1/2”
SQUARE EA
1.00
J
BY6061
66061
3/8”
2-11/32”
2-11/32”
2-1/2”
SQUARE PKG 2
2.10
G
PIVOT POINT COUPLER PINS
Safety lock pins have pin and cotter all in one assembly. The wire loop is pulled over the pin end to lock it in place
or remove it. Quick connect or disconnect prevents coupler latch from accidentally opening. Tempered spring with
carbon steel pin zinc plated.
A
B
C
D
DIA USABLE
LOOP
PIN
PART #
MFG #
WIDTH LENGTH CLEARANCE LENGTH STYLE
UM
PT110
WIRE-1RD 1/4”
1-3/4”
1-1/2”
2”
ROUND EA
1.95
L
PT115
WIRE-3RD 5/16”
2-5/16”
2”
2-3/4”
ROUND EA
1.95
L
PT101
WIRE-3SQ 5/16”
2-3/8”
1-3/4”
2-3/4”
SQUARE EA
1.95
L
PT107
WIRE-7SQ 3/8”
2-1/8
1-1/2”
2-1/2”
SQUARE EA
1.95
L
BUYERS LYNCH PINS
A
B
C
D
DIA USABLE
LOOP
PIN
PART #
MFG #
WIDTH LENGTH WIDTH LENGTH STYLE
UM
BY6003
66003
3/16”
1-1/8”
1-5/16”
1-7/16”
FLAT ROUND EA
0.35
B
BY6000
66000
1/4”
1-1/2”
1-11/16
1-3/4”
FLAT ROUND EA
0.45
B
BY6006
66006
5/16”
1-1/2”
1-3/4”
1-3/4”
FLAT ROUND EA
0.40
G
BY6010
66010
7/16”
1-1/2”
1-3/4”
1-3/4”
FLAT ROUND EA
0.55
J
BY6015
66015
7/16”
1-1/2”
1-3/4”
1-15/16”
FLAT ROUND EA
0.80
J
PIVOT POINT LYNCH PINS
A
B
C
D
DIA USABLE
LOOP
PIN
PART #
MFG #
WIDTH LENGTH WIDTH LENGTH STYLE
UM
PT226
HANG-2
3/16”
1-1/4”
1-7/16”
1-1/2”
FLAT ROUND EA
1.40
L
PT224
HANG-4
1/4”
1-1/2”
1-11/16”
1-3/4”
FLAT ROUND EA
1.60
L
PT225
HANG-6
5/16”
1-5/16”
1-1/2”
1-3/4 FLAT ROUND EA
1.75
L
BUYERS HITCH PINS
A
B
C
D
DIA USABLE HAIR PIN
PIN
PART #
MFG #
WIDTH LENGTH WIDTH LENGTH STYLE
UM
BY6100
66100
1/2”
4-3/8”
PT027
4-15/16”
LOOP END EA
2.50
J
BY6105
66105
5/8”
6-5/16”
PT027
6-15/16”
LOOP END EA
4.95
H
BY6110
66110
3/4”
4-7/16”
PT029
4-15/16”
LOOP END EA
3.95
G
BY6115
66115
3/4”
6-1/4”
PT029
7”
LOOP END EA
4.95
H
BY6120
66120
7/8”
6-5/16”
PT029
6-15/16”
LOOP END EA
4.75
G
BY6125
66125
1”
6-1/4”
PT029
6-3/4”
LOOP END EA
6.90
H
PIVOT
POINT
PIVOT
POINT
