TRAILER
UNDER 80” WIDE COMBINATION TAIL LIGHTS
STOP, TURN, & TAIL LIGHTS
• Under-80” combination tail light. Includes the following functions: stop, turn, tail, rear reflex,
side marker, side reflex, and license light (
PM444
only) • Mounts on 2” centers and includes
mounting hardware • Grounds through 1/4” mounting studs • These lights also replace lights
on
PM540
and
PM541
light kits
V440
OVER 80” WIDE SUBMERSIBLE COMBINATION TAIL LIGHTS
• Under-80” combination tail light. Includes the following functions: stop, turn, tail, rear reflex,
side marker, side reflex, and license light (
PM4521
only) • Mounts on 2” centers and includes
mounting hardware • Grounds through mounting studs • These lights also replace lights on
PM544
light kit
V452
OVER 80” WIDE SUBMERSIBLE COMBINATION TAIL LIGHTS
V456
• Low-profile, over-80” submersible combination tail light • Includes the following
functions: stop, turn, tail, rear clearance, rear reflex, side marker, side reflex, and
license light (
PM4561
only) • Grounds through separate lead wire • Mounts on
slide-on 2” centers and includes mounting hardware • These lights also replace
lights on
PM547
light kit
SEALED ROUND 4” STOP, TURN, & TAIL LIGHT
V426R
• Sealed, 4” round stop, turn, and tail light may be used on both curbside and
roadside of vehicle or trailer • Features extra wide, spin welded, tongue-and-groove
lens lip and waterproof seal • Can be purchased as a kit with grommet and 3 wire
plug or each piece can be purchased separately.
SEALED OVAL STOP, TURN, & TAIL LIGHT
V421R
• Sealed, oval stop, turn, and tail light may be used on both curbside and roadside
of vehicle or trailer • Legal in either horizontal or vertical position • Polycarbonate
lens is welded to housing to form single unit • Can be purchased as a kit with
grommet and 3 wire plug or each piece can be purchased separately.
UNIVERSAL MOUNTING BRACKET
• Black powder-coat finish
• 3” wide x 4-1/2” tall
• For use with most Peterson stud mount lights
510-9
PART #
MFG # DESCRIPTION
PM5109
510-9 Black Steel - Bulk
3.95
G
PART #
MFG # DESCRIPTION
PM4210
V421KR Light Kit
11.95
G
PM421
V421R Light Only
9.95
G
PM42118
421-18 Grommet Only
2.95
G
PM431491
431-491 3-Wire Plug Only
2.95
G
PART #
MRF # DESCRIPTION
PM4260
Y426KR Light Kit
12.95
G
PM426
426R Light Only
6.95
G
PM42618
426-18 Grommet Only
2.95
G
PM431491
431-491 3-Wire Plug Only
2.95
G
PART #
MFG # DESCRIPTION
PM456
M456 6 Function RH
16.95
G
PM4561
M456L 7 Function LH
16.95
G
PART #
MFG # DESCRIPTION
PM452
V452 6 Function RH
12.95
G
PM4521
V452L 7 Function LH
6.95
G
PM44015
440-15 Rear Replacement Lens
2.95
G
PM5615
56-15R Side Replacement Lens
2.95
G
PART #
MFG # DESCRIPTION
PM440
V440 6 Function RH
8.95
G
PM444
V440L 7 Function LH
8.95
G
PM44015
440-15 Rear Replacement Lens
2.95
G
PM5515
55-15R Side Replacement Lens
2.95
G
