30 / 334
AXLES, HUBS & SPRINGS
30
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
How to measure for u-bolts:
A = Rod width - threads per inch
B = Between leg length (inside thread)
C = Leg length
D = Thread length
TIE DOWN U-BOLT KITS
Used for mounting brackets to trailer frame. Zinc plated to help prevent rusting.
Includes flat washers and nyloc nuts.
OCK NUTS
PART #
MFG #
SIZE U/M
LR10627
10627
3/8"-16 EA
0.28
L
LR10654
10654
7/16"-14 EA
0.25
L
LR10645
10645
1/2"-13 EA
0.35
L
WASHERS
PART #
MFG #
SIZE U/M
LR10502
10502
3/8"
EA
0.20
L
LR10510
10510
7/16"
EA
0.25
L
LR10573
10573
1/2"
EA
0.25
L
PART # MFG #
"A"
RODWIDTH
"B"
BETWEEN LEG
"C"
LEG LENGTH
"D"
THREAD LENGTH SHAPE
EACH/
PAIR
LR86204
86204
1/2-13
2-1/8"
4"
2"
SQUARE PAIR
10.88
G
276005
86205
1/2"-13
3-1/8"
3"
1-1/2"
SQUARE PAIR
9.47
G
276006
86206
1/2"-13
3-1/8"
4"
2"
SQUARE PAIR
9.83
G
276007
86207
1/2"-13
4-1/8"
3"
2"
SQUARE PAIR
10.02
G
276008
86208
3/8"-16
2-1/8"
4"
1-3/4"
SQUARE PAIR
10.23
G
276009
86209
3/8"-16
3-1/8"
3"
1-3/4"
SQUARE PAIR
9.18
G
276010
86210
3/8"-16
3-1/8"
4"
1-3/4"
SQUARE PAIR
9.47
G
276011
86211
3/8"-16
4-1/8"
3"
1-3/4"
SQUARE PAIR
9.63
G
276012
86212
7/16"-14
1-9/16"
3-9/16"
2"
SQUARE EACH
5.26
G
276013
86213
1/2"-13
1-9/16"
4-1/16"
2"
SQUARE EACH
6.20
G
276014
86214
1/2"-13
3-1/16"
3-13/16"
1-1/2"
SQUARE EACH
6.10
G
276015
86215
1/2"-13
2-1/16"
4-13/16"
2"
SQUARE EACH
6.51
G
276016
86216
3/8"-16
1-3/4"
4-13/16"
1-3/4"
ROUND EACH
4.59
G
276017
86217
1/2"-13
2-3/8"
5-3/8"
2"
ROUND EACH
6.87
G
276018
86218
1/2"-13
3-1/16"
6-11/16"
2"
ROUND EACH
8.22
G
276019
86219
3/8"-16
1-5/8"
3-9/16"
1-3/4"
SQUARE EACH
4.35
G
276020
86228
7/16"-14
1-9/16"
3-9/16"
2"
SQUARE EACH
4.81
G
276021
86229
7/16"-14
2-1/16"
4-5/16"
2"
SQUARE EACH
5.21
G
276022
86230
7/16"-14
3-1/16"
3-5/16"
1-3/4"
SQUARE EACH
5.21
G
276023
86231
7/16"-14
3-1/16"
4-5/16"
2"
SQUARE EACH
5.29
G
276024
86234
7/16"-14
4-1/16"
2-13/16"
1-3/4"
SQUARE EACH
5.36
G
