Years
Bore x
Stroke
(mm)
Bore
Size
(mm)
Top End
Kit No.
Wiseco
Piston
Part No.
Repl
Ring Set
Part No.
Repl
Pin
& Clips
Top End
Gasket Kit
Top End
Bearing
POLARIS CONTINUED
ATV 2-Stroke
ATV300
94-00 74.5 74.50
101337 721M07450 2933TD S513 W5667
B1014
Pro-Lite
x
75.00
101338 721M07500 2953TD
65 75.50
101339 101931 2973TD CW18
76.00
102579 103533 2992TD
76.50
102580 103534 3012TD
Trail Boss 350
All
80 80.00
101956 639M08000 3150TD S278 W5423
B1002
x
80.50
101957 639M08050 3169TD
70 81.00
101958 103898 3189TD CW18
81.50
101677 103586 3209TD
82.00
101678 103587 3228TD
ATV 400
thru 03
83 83.00
103553 675M08300 3268TD S278 W5517
B1002
x
83.25
103554 101565 104339
70 83.50
103555 675M08350 3287TD CW18
84.00
103556 101567 104342
84.50
103597 101839 104344
85.00
103598 101840 104345
ATV 4-Stroke
Outlaw 450 MXR
08-11
89 89.00
-----
4941M08900 8900ZC S641 W5883
-----
ArmorGlide skirt coated
X 91.00
-----
-----
9100ZC
11:1 Compression
72
111635
Cylinder boring/ replating
required for oversizes.
Outlaw 450 MXR
08-11
89 89.00
-----
4942M08900 8900ZC S641 W5883
-----
ArmorGlide skirt coated
X 91.00
-----
-----
9100ZC
12:1 Compression
72
111635
Cylinder boring/ replating
required for oversizes.
Outlaw 450 MXR
08-11
89 89.00
-----
4959M08900 8900ZC S641 W5883
-----
ArmorGlide skirt coated
X
13.5:1 Compression
72
111635
500 Xplorer
97
92 92.00
101912 4677M09200 3622XC S591 W5747
-----
ATP 500 H.O.
04-05
x
92.50
101913 4677M09250 3642XC
1996-07
Sportsman
96-08
75 93.00
101914 4677M09300 3661XC CW23
Scrambler
97-08
Ranger 500
99-07
Magnum 500
96-03
Big Boss 500
98
ATV Pro 500
02
10.2:1 Compression
Cylinder boring required for
oversizes
Predator
03-07 99.2 99.20
101255 4807M09920 3905XK S626 W6195 W6196
-----
High-Compression 12.5:1
x 104.83
101230
-----
4127GFX
99.2mm 104.83mm
Cylinder resleeving required
64.6
2003-04 2003-04
for oversizes
Outlaw 500 LE
06-07 99.2 99.20
101255 4807M09920 3905XK S626 W6195 W6196
-----
x 104.83
101230
-----
4127GFX
99.2mm 104.83mm
Cylinder resleeving required
for oversizes
64.6
2003-04 2003-04
Outlaw 525
07-08
95 95.00
-----
4731M09500 9500ZS S641 W5885
-----
Stock Compression 11:1 Ratio
x
97.00
-----
-----
9700ZS
72
CW20
Outlaw 525
07-08
95 95.00
-----
4732M09500 9500ZS S641 W5885
-----
High Compression 12.5:1 Ratio
x
97.00
-----
4732M09700 9700ZS
72
CW20
Ranger RZR 570
12-13
99 99.00
-----
112020 100298 S747
-----
x
10.2:1 Compression
ArmorGlide skirt coated
73.6
111695
