Years
Bore x
Stroke
(mm)
Bore
Size
(mm)
Top End
Kit No.
Wiseco
Piston
Part No.
Repl
Ring Set
Part No.
Repl
Pin
& Clips
Top End
Gasket Kit
Top End
Bearing
YAMAHA CONTINUED
ATV 4-Stroke
YFM660R Raptor
01-05
100 100.00
102195 101196 3937XS
W6017
-----
x 100.50
102196 101197 10050XS
101mm
84 101.00
102197 101198 10100XS CW22
9.9:1 Compression
102.00
101965 101119 10200XS
W6315
Cylinder boring required for
102mm
oversizes
ArmorGlide skirt coated
YFM660R Raptor
01-05
100 100.00
102367 4737M10000 3937XS
W6017
-----
x 100.50
102368 4737M10050 10050XS
101mm
84 101.00
102369 4737M10100 10100XS CW22
11:1 High-Compression
W6315
Cylinder boring required for
102mm
oversizes
ArmorGlide skirt coated
YFM660R Raptor
01-05
102 102.00
102732 4811M10200 111595 S655 W6315
-----
x
Big Bore
84
CW22
11:1 Compression
Cylinder boring required for
oversizes
ArmorGlide skirt coated
YFM700 Raptor
06-14
102 102.00
102572 101773 10200XS
W6570
-----
9.2:1 Compression
x 103.00
102573 101774 10300XS
ArmorGlide skirt coated
84
Nikasil Bore - cylinder sleeving or
replating required for oversizes
YFM700 Raptor
06-14
102 102.00
101610 103582 10200XS
W6570
-----
x 103.00
101611 103583 10300XS
ArmorGlide skirt coated
84
11:1 Compression
Nikasil Bore - cylinder sleeving or
replating required for oversizes
700 Grizzly
07-13
102 102.00
102574 101773 10200XS
W6569
-----
700 Rhino
08-09
x 103.00
102575 101774 10300XS
9.2:1 Compression
84
ArmorGlide skirt coated
Nikasil Bore - cylinder sleeving or
replating required for oversizes
700 Grizzly
07-13
102 102.00
101612 103582 10200XS
W6569
-----
700 Rhino
08-09
x 103.00
101613 103583 10300XS
ArmorGlide skirt coated
84
11:1 Compression
Nikasil Bore - cylinder sleeving or
replating required for oversizes
700 Grizzly
14
102 102.00
-----
TBA 10200XS
-----
x 103.00
-----
TBA 10300XS
10:1 Compression
84
ArmorGlide skirt coated
Nikasil Bore - cylinder sleeving or
replating required for oversizes
