2015 ATV / UTV CATALOG
APPLICATION
YEAR
STD
FILTER
PRE-OILED
AIR FILTER
POWERFLOW
KIT
BACKFIRE/
REPL. FILTER
AIR BOX
COVER
OIL
FILTER
YAMAHA
CONTINUED
Rhino 660
05-07
630319 630320
-----
-----
-----
630016
700 Raptor
06-15
630342 630343
630344
630352
-----
630010
700 Grizzly
07-15
630346 630347
-----
-----
-----
630015
700 Rhino
08-14
630358
-----
-----
-----
-----
630015
NOTES
* = Air box covers 630857, 630863, 630887 only work with POWERFLOW Kits.
**= Foam outer cover for Stock Filter
# = Filter that comes with a plastic insert for the rubber flange.
PART NUMBER KIT NOTES
631624
Comes with plastic composite intake flange, backfire filter, and mounting hardware.
630132
Comes with aluminum flange, filter cage, backfire filter, and mounting hardware.
630143
Comes with aluminum flange, filter cage, backfire filter, and mounting hardware.
630206
Comes with aluminum sealing plate, filter cage, backfire filter, and wing bolt.
630208
Comes with wire filter cage and backfire filter.
630232
Comes with wire filter cage, backfire filter. Uses stock mounting hardware.
631634
Comes with Wire Cage and backfire filter
630330
Comes with oversized mounting flange, oversized backfire clamp-on filter and clamp.
CANNOT use AirBox Cover #160092 with this kit.
630344
Comes with plastic adaptor, backfire clamp-on filter, and clamp.
630354
Comes with aluminum flange, backfire clamp-on filter, o-ring, 3 bolts.
630356
Comes with plastic adaptor, backfire clamp-on filter, and 1 clamps.
630323
Comes with aluminum flange, filter cage, air filter, wing bolt, o-ring, and 2 bolts.
630447
Comes with aluminum flange, filter cage, backfire filter, and mounting hardware.
630451
Comes with wire filter cage, backfire filter. Uses stock mounting hardware.
630455
Comes with wire filter cage, backfire filter, air box lid. Uses stock filter bolt.
630538
Comes with aluminum flange, filter cage, backfire filter, and mounting hardware.
631625
Comes with plastic reducer, backfire filter, and mounting hardware.
630548
Comes with plastic composite intake tube, backfire filter, and mounting hardware.
630553
Comes with std. Twin Air filter and wire filter cage.
631567
Comes with plastic intake flange, wire filter cage, and backfire filter.
631616
Comes with plastic filter base and square foam filter
630556
Comes with clamp on filter and plastic reducer and hose clamp.
630568
Comes with a flat wire cage, backfire filter, and black foam spacer.
630569
Comes with plastic adaptor, backfire clamp-on filter, and 2 clamps
630575
Comes with std. Twin Air filter and wire filter cage.
630577
Comes with spring and Twin Air Backfire Filter.
631618
Comes with spring and Twin Air Backfire Filter.
CROSS REFERENCE/SIZING CHART
These filters have either rubber on the top and bottom or have a hole in the top to accept a filter cage.
PART NUMBER
RUBBER
DIAMETER
WIDTH
FILTER
DIAMETER
LENGTH
FILTER
LENGTH
RUBBER
FILTER
SHAPE
630119
73 mm 110 mm 100 mm 15 mm Round
630122
73(10)mm 110 mm 100 mm 10 mm Round
630124
73(8)mm 110 mm 130 mm 15 mm Round
630128
57(8)mm 100 mm 85 mm 15 mm Round
630129
90(8)mm 125 mm 110 mm 10 mm Round
630134
90(8)mm 125 mm 110 mm 10 mm Round
630135
90(8)mm 125 mm 110 mm 10 mm Round
630136
90 mm 125 mm 120 mm 10 mm Round
TWIN AIR ATV FILTERS continued
