BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
139
2015 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
INDUSTRY LEADING TRAILER BRAKE CONTROLS
P3
®
taking
innovation
to a whole new
level
After receiving valuable insight from industry experts and our own customers, Tekonsha® did
something truly amazing: We listened and responded. The result is the P3; the industry’s most
advanced trailer electric brake control. A true proportional braking system, P3 has several added
features, making it the new standard for electric trailer brake controls.
• A distinct, easy-to-read LCD display with multiple screen color options
• “Up-Front” controls provide easy access to all P3 features
• Easy to understand diagnostics show output current, battery/brake/output voltage
• A “flashing red” warning system alerts user to “No Trailer Brake” situations
• Select Electric over Hydraulic or Electric trailer brake mode
• Screen information display in English, French or Spanish
• “The Original Boost” feature allows for different levels of customized braking
• Compact, dash-hugging design
• Unique, easy-to-use, clip-mounting system
• Quick disconnect feature for easy storage
• Electric trailer brake control for up to 4 braking axles
• Limited lifetime warranty (some conditions apply)
• Display boxed - complete as shown
8590195 195.16
B
ACCESSORIES FOR P3
®
PART #
DESCRIPTION
855904 2.96
B Dash Mounting Clip Bracket
852178 4.80
E Mounting Bracket Kit
857894 15.09
E 3 Ft. Pigtail Harness Kit
855901 3.50
B T-Slot Bracket
PRODIGY
®
P2
advanced
intelligence
ACCESSORIES FOR PRODIGY
®
P2
PART #
DESCRIPTION
857686 10.35
E Dash Pocket Mounting Kit
857685 6.23
E Mounting Bracket
857894 15.09
E 3 Ft. Pigtail Harness Kit
• Reverse battery protection for both vehicle and breakaway
• Designed to work with electric over hydraulic brake systems
• Numerous mounting options – including 360 degree vertical rotation
• Digital display depicts voltage delivery to trailer during braking
• No level adjustment necessary – adjusts to varying terrain as you drive
• Great for backing into tough spots! Works proportionally in reverse - with the ability to disable
when not needed
• Produces stops that are in proportion to vehicle’s deceleration rate
• “Boost” feature gives users the ability to apply more initial trailer braking power
when towing heavier trailers
• Continual diagnostics check for proper connection, shorted magnet conditions
and much more
• Quick and easy disconnect feature allows user to remove and store the control
when not in use
• Electric trailer brake control for up to 4 braking axles
• Limited lifetime warranty (some conditions apply)
• Display boxed - complete as shown
852178
857894
857894
857686
857685
7-WAY TRAILER EMULATOR
7-Way Trailer Emulator is used for the proper installation and set-up of a brake control when a trailer is
not readily available. Brake control set-up is accomplished using a built-in load module that will stimulate
electric magnet brakes on a trailer. (The emulator will also check electrical continuity of all circuits in
the 7-way blade style connector.)
890885 167.24
B
856560 39.21
E
855904
855901
