2015 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
BREAKAWAY SYSTEMW/CHARGER -
for use on
1 & 2
axle
trailers with electric brakes
For use on 1, 2, 3, and 4 axle trailers equipped with electric brakes. These complete systems incorporate the highest quality components in trailer
breakaway systems. Meet or exceed Department of Transportation (DOT) specifications regarding trailer breakaway and holding requirements. If a
breakaway occurs between your tow vehicle and your trailer, the breakaway systems will automatically apply consistent braking power to your trailer
brakes. Quick and easy to install, the systems come with a weather/corrosion resistant, heavy-duty polymer case to protect the battery and charger.
BREAKAWAY SYSTEM -
for use on
1 & 2
axle
trailers w
/
electric brakes
PART #
DESCRIPTION
851026 46.99
E Includes
852018
Polymer Battery Case w/A-Frame or Post Mounting Bracket;
852023
Rechargeable Sealed 12v 5 Amp-hr. Lead Acid Battery & Terminals;
852005
Breakaway Switch
BREAKAWAY SYSTEM -
for use on
1, 2, 3 & 4
axle
trailers w
/
electric brakes
PART #
DESCRIPTION
852026 48.50
E Includes
852018
Polymer Battery Case w/A-Frame or Post. Lead Acid Battery &
Terminals;
852010
Breakaway Switch
8520005 41.40
E Includes
852051
Lockable All Polymer Battery Case w/Flat. Lead Acid Battery &
Terminals;
852010
Breakaway Switch
PART #
DESCRIPTION
851028 53.12
E Includes
852018
Polymer Battery Case w/A-Frame or Post Mounting Bracket;
852023
Rechargeable Sealed 12v 5 Amp-hr . Lead Acid Battery & Terminals;
852005
Breakaway
Switch;
851024
9.55
E DC-to-DC Accelerated Battery Charging Device (ABCD)
BREAKAWAY SYSTEMWITH CHARGER -
for use on
1, 2, 3 & 4
axle
trailers w
/
electric brakes
PART #
DESCRIPTION
852028 61.56
E Includes
852018
Polymer Battery Case w/A-Frame or Post Mounting Bracket;
852023
Rechargeable Sealed 12v 5 Amp-hr. Lead Acid Battery & Terminals;
852010
Break-
away Switch
8520015 56.71
E Includes
852051
Lockable All Polymer Battery Case w/Flat Lead Acid Battery & Ter-
minals;
852010
Breakaway Switch
PUSH TO TEST BREAKAWAY SYSTEM
Push to test: LEDs indicate fully charged, charging, or recharge • Multi-stage integrated charger provides a fast
recharge up to 12.8 volts. Once battery is fully charged, the automatic float mode is designed to provide a continuous
charge without overcharging • Activates trailer brakes upon separation of trailer and tow vehicle • For use on 1,2,
or 3 axle trailers equipped with electric brakes • Weather/corrosion resistant, heavy-duty polymer case to protect
battery and charger • Quick and easy to install • Breakaway switch w/7.5” lead wires • 5 samp/hr battery • Battery
box, dimensions - 5” x 4.125” x 4” • Weight - 4.95 lbs. • Note: make sure battery is fully charged prior to towing
PART #
DESCRIPTION
85313
50.52
E Push To Test Breakaway System w/Charger
SEALED LEAD ACID BATTERY
12v, sealed lead acid battery for use with Breakaway Systems on single, tandem and tri-axle trailers equipped with
electric brakes. Battery requires periodic recharging to maintain optimum performance.
PART #
DESCRIPTION
852023 22.95
B 5 Amp-hr Sealed Battery
TRAILER ELECTRIC BREAKAWAY SYSTEMS & ACCESSORIES
BATTERY CASES
Rust-proof heavy duty polymer cases protect battery and charger from elements and corrosion. Featuring
U-shaped clamp style fastener on
852018
to mount over most trailer tongues,
852051
is a lockable case.
PART #
DESCRIPTION
852018 11.82
E Battery Case - One-Bolt Installation on Jackpost or A-Frame
852051 6.22
E Battery Case - Four-Bolt Installation on Flat Surface
852018
852028
8520005
