AXLES, HUBS & SPRINGS
21
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
FLEXIRIDE SUSPENSION UNIT
PART # MFG #
WEIGHT
SPINDLE
SIZE
HUB
USED
SPINDLE
BEARING
SPINDLE
NUT
SPINDLE
WASHER
SPINDLE
COTTER PIN
FR935
FR-935
249.20
B 935#
1" STRAIGHT
N/A LM44643 ANT1
SWP1
CP2
FR1400
FR1400B
285.40
B 1400# 1-1/16" STRAIGHT N/A LM44649 ANT1
SWP1
CP2
FR2000*
FR-2000
348.95
H 2000# 1-1/16" STRAIGHT N/A LM44649 ANT1
SWP3
CP2
*HAS A GREASABLE SPINDLE, NEEDS LOCK WASHER PART #
230058
SPRING SEAT
PART # MFG #
AXLE
WIDTH
SPRING
WIDTH
690996
SS100
2.55
H 1-3/4"
1-3/4"
690997
DX3-8
5.95
L 2-3/8"
1-3/4"
• Flexiride allows independent suspension for each wheel
• Each piece is completely independent of one another
• Will fit any width trailer. Weld base plate to cross member, check to be square with frame (very important)
• Bolt flexiride arm to base plate with arm trailering to rear of trailer
• 3 sizes available
• Sold in pairs
• Base plates extra - sold each (order 2 for pair)
• Note: Spindle nut, washer, and cotter pin must be ordered separately
SPINDLE WASHERS
PART # MFG #
STYLE SIZE U/M
SWP34
SW-750
1.60
N A 3/4"
EA
SWP1
11070
0.62
E A 1"
EA
SWP3
SW3
0.90
L B 1-3/16"
EA
SWP2
SW-2
1.25
L C TONGUE EA
230058
FS12-12
0.95
G C TONGUE EA
SPINDLE NUTS
PART # MFG #
STYLE SIZE U/M
ANT1
11065
2.18
L SLOTTED 1"
EA
SPINDLE COTTER PIN
PART # MFG #
A
B U/M
CP2
11075Z
0.17
G 2"
1/8" EA
CP103
SCP103
0.30
H 1-15/16" 3/8" EA
SPINDLE NUT LOCK SHIELD
PART # MFG #
A
B U/M
75-813
LS813
1.55
G .845"
1.140" EA
SPINDLE NUT KITS
PART # MFG #
NUT
WASHER COTTER PIN U/M
230010
230010
2.40
L ANT1 SWP1
CP2
EA
230011
230011
2.70
L ANT1 SWP3
CP2
EA
