TRAILER
WHEEL BOLTS
PART # MFG #
A
LENGTH
B
LENGTH
C
DIAMETER
THREAD STYLE U/M
75-5024
ST-502-04
1.50
G 1.813"
.438"
.543"
1/2"-20 PRESS IN EA
75-500
ST-500
1.65
G 2"
1.063"
.688"
1/2"-20 SCREW IN EA
WBP5
WBP-5
1.00
L 1-3/4"
1/4"
1/2"
1/2"-20 PRESS IN EA
WBP3
WBP-3
1.00
L 7/8"
1/4"
3/8"-24 PRESS IN EA
WHEEL BOLTS, NUTS, AND KITS
PART # MFG #
THREAD DESCRIPTION U/M
WBT12
11060
1.03
J 1/2"-20 WHEEL BOLT EA
LNT12
11051
0.25
H 1/2"-20
LUG NUT
EA
LNT76
LN76
0.50
L 7/16"-20
LUG NUT
EA
230012
230012
5.25
L 1/2"-20 WHEEL BOLT PKG 5
230013
230013
1.95
L 1/2"-20
LUG NUT
PKG 5
230014
230014
3.25
L 7/16"-20
LUG NUT
PKG 5
LNT12 / LNT76
WBT12
230013
230012
PART # MFG #
THREAD SIZE U/M
855791
5791
21.80
E 1/2"-20 1-7/8" PKG 5
RIM CLAMP BOLTS
RIM CLAMP NUTS
PART # MFG #
THREAD U/M
855794
5794
8.05
E 1/2"-13 PKG 5
855795
5795
8.95
E 1/2"-20 PKG 5
855794
