WRIST pins
OD LENGTH
PART #
mm mm
S256 16.90
G 16.0000 52.00
S257 16.90
G 18.0000 56.00
S259 16.90
G 16.0000 58.40
S270 16.90
G 16.0000 46.99
S271 16.90
G 16.0000 57.00
S272 16.90
G 18.0000 58.50
S277 16.90
G 18.0000 65.50
S278 16.90
G 18.0000 62.81
S280 16.90
G 18.0000 54.99
S330 16.90
G 17.0000 61.70
S343 16.90
G 18.0000 60.00
S376 16.90
G 19.0000 63.50
S394 16.90
G 14.0000 48.00
S419 14.96
G 22.0000 54.00
S423 16.90
G 20.0000 55.50
S459 16.90
G 18.0000 47.00
S461 16.90
G 20.0000 65.00
S467 16.90
G 15.0000 50.00
S475 14.50
G 19.0000 58.50
S477 16.90
G 18.0000 52.70
S482 16.90
G 18.0000 49.50
S484 16.90
G 18.0000 58.20
S485 16.90
G 14.0000 45.25
S486 16.90
G 16.0000 55.25
S508 16.90
G 18.0000 53.50
S511 16.90
G 18.0000 57.00
S512 16.90
G 20.0000 60.00
UNChromedWrist Pins
(2 - 4-cycle use Only)
Part #
Description
CW10
2.00
G
10 mm Circlip
CW12
2.00
G
12 mm Circlip
CW13
2.00
G
13 mm Circlip
CW14
2.00
G
14 mm Circlip
CW15
2.00
G
15 mm Circlip
CW16
2.00
G
16 mm Circlip
CW17
2.00
G
17 mm Circlip
CW18
2.00
G
18 mm Circlip
CW19
2.00
G
19 mm Circlip
CW20
2.00
G
20 mm Circlip
CW21
2.00
G
21 mm Circlip
CW22
2.00
G
22 mm Circlip
CW23
2.00
G
23 mm Circlip
CW24
2.00
G
24 mm Circlip
• High strength
• Easy to install
• Two furnished with every piston
• Additional sets can be ordered as separate components
OD LENGTH
PART #
mm mm
S520 14.50
G 20.0000 60.00
S522 17.67
G 15.0000 56.00
S523 17.67
G 17.0000 61.70
S524 14.50
G 18.0000 57.00
S527 17.67
G 21.0000 54.00
-----
24.0000 63.50
S529 17.67
G 21.0000 70.00
S532 17.67
G 17.0000 43.00
S533 17.67
G 17.0000 52.35
S549 14.50
G 20.0000 50.85
S550 14.50
G 22.0000 50.85
S551 14.50
G 23.0000 50.85
S553 14.50
G 20.0000 55.50
-----
18.0000 62.81
S571 17.67
G 15.0000 44.50
S591 17.67
G 23.0000 54.00
S592 17.67
G 13.0000 39.00
S593 17.67
G 14.0000 44.00
-----
16.0000 57.00
S600 17.67
G 18.0000 47.00
S615 17.67
G 19.0000 50.44
S626 13.60
G 23.0000 63.50
S641 14.50
G 20.0000 50.44
S646 17.67
G 16.0000 44.40
S655 14.50
G 22.0000 57.15
S660 17.67
G 19.0000 50.44
S686 15.37
G 16.0000 41.50
ChromedWrist Pins
(4 - cycle use Only)
OD LENGTH
PART #
mm mm
S514 16.90
G 16.0000 44.50
S517 16.90
G 14.0000 38.35
S538 16.90
G 12.0000 39.00
S539 16.90
G 22.0000 63.50
S544 18.59
G 20.0000 74.50
S563 16.90
G 12.0000 31.00
S595 16.90
G 12.0000 36.00
S630 16.90
G 10.0000 32.90
S631 16.90
G 20.0000 60.00
S632 16.90
G 15.0000 47.00
S637 16.90
G 16.0000 44.00
S640 16.90
G 22.0000 63.50
S650 16.90
G 20.0000 65.00
S651 17.67
G 24.0000 68.00
S662 17.67
G 22.0000 69.85
S668 16.90
G 15.0000 47.00
S671 17.67
G 13.0000 29.75
S677 17.67
G 16.0000 40.00
PISTON CIRCLIPS
