BRONCO CONNECTING RODS
Product Features:
• Brass coated surface
• Washer: Silver or zinc coating
• Crank Pin: SCM-415 chromoly, hardness RC 58-62
• Road SCM420 chromoly, double honing on both top and bottom bearing holes
• Top/bottom bearing: SCM415 chromoly with silver coating for added heat resistance
MODEL
YEAR PART #
B
BEARING
T
BEARING PIN WASHER B C A D E (D X L)
ARCTIC CAT
DVX400
04-08
120707 78.95
L YES
NO YES NO 20 43 107 20 22 35 X 61.85
HONDA
ATC185S
80-83
120708 37.95
L YES
NO YES YES 15 38 103.5 16 16 30 X 53.8
ATC200E/M/S/X
81-85
120708 37.95
L YES
NO YES YES 15 38 103.5 16 16 30 X 53.8
TRX200
84
120708 37.95
L YES
NO YES YES 15 38 103.5 16 16 30 X 53.8
ATC250R
85-86
120660 67.95
L YES
YES YES YES 22 31 125.3 20 16.75 24 X 59.5
TRX250R
86
120660 67.95
L YES
YES YES YES 22 31 125.3 20 16.75 24 X 59.5
120660 WITH 2PCS EXTRA WAHSERS , SIZE IS 24.2 X 39.8 X 1.0MM VESRAH IS NOT OEM REPLACEMENT EXACTLY AS LISTED AS
VESRAH CHANGED THE HEIGHT OF THE TOP END(D) TO 17MM FROM 20MM
TRX300FW
88-00
120709 48.95
L YES
NO YES YES 17 41 122 20 20 33 X 59.8
TRX300EX/X
93-09
120709 48.95
L YES
NO YES YES 17 41 122 20 20 33 X 59.8
TRX300FW
88
90-00
120709 48.95
L YES
NO YES YES 17 41 122 20 20 33 X 59.8
TRX350FE/FM/TE/TM 00-06
120710 58.95
L YES
NO YES YES 20 41 116 20 17 33 X 60
TRX 400 EX/X
99-09
679139 TBA
YES
NO YES NO 20 43 122.6 17 21 34 X 66
TRX400FW
95-01
120712 59.95
L YES
NO YES YES 19 41 122.5 20 20 33 X 62.8
TRX450S/ES
98-01
120712 59.95
L YES
NO YES YES 19 41 122.5 20 20 33 X 62.8
TRX450R/ER
04-05
679140 81.95
L YES
NO YES YES 21 46 111.5 19 23.5 35 X 62.7
TRX450R/ER
06-12
679141 99.95
L YES
NO YES YES 19 42 105.5 18 20 34 X 65
*AT-09193 ALSO FITS CRF450X 2004-12
KAWASAKI
KLF300 A/B BAYOU
86-04
120714 64.95
L YES
NO YES YES 18 43 117 18 22.6 32 X 58.1
KLF 300 C BAYOU 4X4
89-05
KEF 300 LAKOTA/SPORT 95-03
KVF 300/4X4 PRAIRIE 99-02
KFX 400
03-06
120707 78.95
L YES
NO YES NO 20 43 107 20 22 35 X 61.85
POLARIS
P250 TRAIL BLAZER
90-06
120716 67.95
L YES
YES YES YES 23 33 120 18 18 25 X 56
WISECO IS NOT AN OEM REPLACEMENT EXACTLY AS THEY HAVE CHANGED THE I.D.OF TOP END TO BE 34MM FROM 33MM
P250R/ES TRAIL BOSS
2X4/4X4
87-99
120716 67.95
L YES
YES YES YES 23 33 120 18 18 25 X 56
P250 XPLORER 4X4
00-01
250 BIG BOSS 6X6
91-93
P300 2X4/4X4
94-95
P300 BIG BOSS 4X6
89-92
P300 BIG BOSS 6X6
94
P300 XPLORER 4X4
96-99
P300 XPRESS 2X4
96-99
P425L MAGNUM
2X4/4X4/6X6
95-98
120717 72.95
L YES
NO YES YES 23 43 130 22 22 34 X 71
P400L SPORTSMAN 4X4 01
P335 SPORTSMAN 4X4 99-00
