2015 ATV / UTV CATALOG
APPLICATION YEAR DESCRIPTION
PART #
HONDA
TRX400FA 04-05 O-RING 4X7X1.5MM X 1PC, O-RING 3X5X1MM X 1PC, WASHER 3X6.8X0.5MM X 1PC ZINC
PLATE,WASHER 3X5X0.5MM X 2PCS ZINC PLATE, NEEDLE CLIP X 1PC ZINC PLATE, MAIN
JET #140 X 1PC, MAIN JET #98 X 1PC, PILOT JET #45 X 1PC, SHORT SPRING 9.6X5MM
X1PC, NEEDLE JET D464 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC,
RUBBER GASKET X 1PC, NEEDLE SEAT X 2PCS, PILOT JET SEAT X 1PC
679421 15.95
L
TRX400FGA 04-05 BOLT 4 X 47MM GOLD PLATE X 1PC, O-RING X5PC, NEEDLE JET CLIP X 1PC, WASHER
3X6.8X0.5MM X 1PC ZINC PLATE, WASHER 4.5X10X0.7MM X 1PC GOLD PLATE, WASHER
3X5.2X0.5MM X 1PC ZINC PLATE, MAIN JET #85 X 1PC, MAIN JET #130 X 1PC, PILOT
JET #45 X 1PC, LONG SPRING 29.5 X 6.8MM X 1PC, SHORT SPRING 9.7X4.8MM X1PC,
NEEDLE JET D562 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER
GASKET X 1PC, SEAT #140 X 1PC
679421 15.95
L
TRX450ES/S 98-03 BOLT 4 X 47MM GOLD PLATE X 1PC, O-RING X5PC, NEEDLE JET CLIP X 1PC, WASHER
3X6.8X0.5MM X 1PC ZINC PLATE, WASHER 4.5X10X0.7MM X 1PC GOLD PLATE, WASHER
3X5.2X0.5MM X 1PC ZINC PLATE, MAIN JET #85 X 1PC, MAIN JET #130 X 1PC, PILOT
JET #45 X 1PC, LONG SPRING 29.5 X 6.8MM X 1PC, SHORT SPRING 9.7X4.8MM X1PC,
NEEDLE JET D562 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER
GASKET X 1PC, SEAT #140 X 1PC
679398 15.95
L
TRX500FW 01-04 BOLT 4 X 47MM GOLD PLATE X 1PC, O-RING 4X7X1.5MM X 3PCS, O-RING 3X5X1MM
X 2PCS, O-RING 15.5X19.5X2MM X 1PC, O-RING 20X24X2MM X 1PC, WASHER
4.5X10X0.7MM X 1PC GOLD PLATE, WASHER 3X5.2X0.5MM X 1PC ZINC PLATE, NEEDLE
CLIP X 1PC ZINC PLATE, MAIN JET #158 X 1PC, MAIN JET #85 X 1PC, PILOT JET #45 X
1PC, LONG SPRING 32 X 6.8MM X 1PC, SHORT SPRING 9.6X5MM X1PC, NEEDLE JET
D464 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC,
SEAT X 1PC.
679420 15.95
L
TRX500
FOREMAN
05-07 O-RING 4X7X1.5MM X 2PCS, O-RING 2.5X5.5X1.5MM X 2PCS, O-RING 3X5X1MM X 1PC,
WASHER 3X5X0.5MM X 1PC ZINC PLATE, NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET
#162 X 1PC, MAIN JET #60 X 1PC, PILOT JET #45 X 1PC, SHORT SPRING 9.6X5MM X1PC,
NEEDLE JET D516 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER
GASKET X 1PC, NEEDLE SEAT X 2PCS, PILOT JET SEAT X 1PC
679422 15.95
L
TRX300EX
93-08 O-RING 7 X 4 X1.5MM X 2PCS;5 X 3 X 1MM X 2PC;23.6 X 19 X 2.3MM X 1PC; RUBBER
GASKET X 2PCS; WASHER 5 X 3 X 0.5MM X 1PC; SPRING 4.9 X 3.3 X 9.5MM X 1PC;
NEEDLE CLIP X 1PC; MAIN JET #122 X 1PC; PILOT JET #38 X 1PC; NEEDLE JET #D255 X
1PC; FLOAT VALVE X 1PC; NEEDLE SEAT 2.5 X 1PC; AIR ADJUST SCREW X 1PC.
679431 15.95
L
KAWASAKI
KLF220
88-98 GASKETX2 PCS, O-RINGX2 PCS,SPRINGX2 PC,WASHER X 2PCS,C-CLIPX1PC, NEEDLE X
3 PCS, JET X 3 PCS,W-CLIPX 1 PC, 1.5MM FLOAT VALVEX1,TOTAL:17 PCS
679405 12.95
L
KLF300 4X4 89-95 GASKETX1 PC, O-RINGX3 PCS,SPRINGX1 PC, WASHER X 1PC, NEEDLE X 2 PCS,JET X 3
PCS,TRI-NEEDLE X 1PC,NEEDLE JETX1PC,TOTAL:13 PCS
679413 12.95
L
KLF300
88-91 GASKETX1 PC, O-RINGX2 PCS,SPRINGX1 PC,WASHER X 1 PC, NEEDLE X 2 PCS,JET X 3
PCS,TRI-NEEDLE X 1PC,NEEDLE JETX1PC,TOTAL:12 PCS
679414 12.95
L
KVF360
03-07 O-RING 3X5X1MM X 1PC, WASHER 3X5X0.5MM X 1PC ZINC PLATE, MAIN JET #155 X 1PC,
MAIN JET #90 X 1PC, PILOT JET #35 X 1PC, SPRING 5X 12.9MM X 1PC, NEEDLE JET D503
X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC, AIR
ADJUST SCREW SEAT X 1PC, SLOW ADJUST SCREW X 1PC
679426 15.95
L
MULE 3010
ALL BOLT 4 X 12MM ZINC PLATE X 1PC, BOLT 4 X 16.5MM ZINC PLATE X 1PC, FLOAT VALVE
CLIP X 1PC, MAIN JET #41.3 X 2PC, MAIN JET #90 X 1PC, MAIN JET #92.5 X 1PC, SPRING
10 X 6.2MM X 1PC, , FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET
X 1PC, BIG PAPER GASKET X 2PCS, SMALL PAPER GASKET X 1PC, FLOAT SHAFT 2.5 X
27MM X 1PC
679399 15.95
L
KVF300
99-02 O-RING 42 X 38 X 2MM X 1PC;O-RING 5 X 3 X 1MM X 1PC;RUBBER GASKET X
1PC;WASHER 5 X 3 X 0.5MM X 1PC ;SPRING 4.9 X 3.3 X 12.5MM X 1PC;MAIN JET #75 X
1PC;MAIN JET #140 X 1PC;PILOT JET #35 X 1PC ;NEEDLE JET #D466X 1PC;NEEDLE
SEAT X 1PC;FLOAT VALVE X 1PC; AIR ADJUST SCREW X 1PC
679437 15.95
L
KVF650
KVF700
02-09
04-06
O-RING 5 X 3 X 1MM X 2PCS; RUBBER GASKET X 2PCS; WASHER 5 X 3 X 0.5MM X
2PCS;PIN X 2PCS; SPRING 4.9 X 3.3 X 9.5MM X 2PCS; SPRING 8.8 X 7.6 X 26MM X 2PCS;
SPRING 11.5 X 10.5 X 114 X 2PCS; MAIN JET #142 X 1PC; MAIN JET #138 X1PC; PILOT
JET #40 X 2PCS; NEEDLE JET #D502 X 2PCS; FLOAT VALVE X 2PCS; AIR ADJUST
SCREW X 2PCS; SLOW ADJUST SCREW X 2PC; MAIN JET SEAT X 2PCS; SEAT X 2PCS
679441 22.95
L
BRONCO ATV CARBURETOR REBUILD KITS continued
