APPLICATION YEAR DESCRIPTION
PART #
POLARIS
TRAIL
BLAZER 250
TRAIL BOSS
250
90-95
88-99
O-RING 22.6 X 19.6 X1.5MM X 1PC;GASKET X 1PC;WASHER 12.2 X 9.1 X 0.5MM X 1PC
(COPPER); SPRING 4.9 X 3.3 X 9.5MM X 1PC; SPRING 6.5 X 5 X 25MM X 1PC; NEEDLE
CLIP X 1PC; PLYSTIC WASHER 7 X 3 X 0.8 X 1PCS; MAIN JET #145 X 1PC; PILOT JET #40
X 1PC ; NEEDLE JET #Y19A X 1PC; FLOAT VALVE X 1PC; FLOAT VALVE SEAT 2.5 X 1PC;
AIR ADJUST SCREW X 1PC; SLOW ADJUST SCREW X 1PC; CHOCK VALVE X 1PCS
679434 15.95
L
2X2/4X4 300
300
XPLORER/
XPRESS
94-95
96-99
O-RING 22.6 X 19.6 X1.5MM X 1PC;GASKETX 1PC;WASHER 12.2 X 9.1 X 0.5MM X 1PC
(COPPER);SPRING 4.9 X 3.3 X 9.5MM X 1PC; SPRING 6.5 X 5 X 25MM X 1PC;NEEDLE
CLIP X 1PC;PLYSTIC WASHER 7 X 3 X 0.8 X 1PCS;MAIN JET #155 X 1PC;PILOT JET #40X
1PC ;NEEDLE JET #Y19AX 1PC; FLOAT VALVE X 1PC; FLOAT VALVE SEAT 2.5 X 1PC; AIR
ADJUST SCREW X 1PC. SLOW ADJUST SCREW X 1PC; CHOCK VALVE X 1PCS.
679435 15.95
L
SPORT/
SPORTSMAN
4X4
400L/
XPLORER
94-95
94-95
O-RING 22.6 X 19.6 X1.5MM X 1PC; GASKETX 1PC;WASHER 13 X 10 X 0.5MM X
1PC(COPPER); SPRING 4.9 X 3.3 X 9.5MM X 1PC;SPRING 6.5 X 5 X 25MM X 1PC; NEEDLE
CLIP X 1PC;PLYSTIC WASHER 7 X 3 X 0.8 X 1PCS;MAIN JET #200 X 1PC;PILOT JET #30
X 1PC;NEEDLE JET #Y241X 1PC; FLOAT VALVE X 1PC;FLOAT VALVE SEAT 2.5 X 1PC;AIR
ADJUST SCREW X 1PC ;SLOW ADJUST SCREW X 1PC;CHOCK VALVE X 1PCS
679436 15.95
L
250 TRAIL
BLAZER
250 XPLORER
4X4
96-00
00
O-RING 22.6 X 19.6 X1.5MM X 1PC;GASKET X 1PC;WASHER 12.2 X 9.1 X 0.5MM X 1PC
(COPPER); SPRING 4.9 X 3.3 X 9.5MM X 1PC;SPRING 6.5 X 5 X 25MM X 1PC;NEEDLE
CLIP X 1PC;PLYSTIC WASHER 7 X 3 X 0.8 X 1PCS;MAIN JET #130 X 1PC;PILOT JET #40 X
1PC ;NEEDLE JET #Y19A X 1PC;FLOAT VALVE X 1PC;FLOAT VALVE SEAT 2.5 X 1PC;AIR
ADJUST SCREW X 1PC ; SLOW ADJUST SCREW X 1PC;CHOCK VALVE X 1PCS
679439 15.95
L
XPLORER 400 97-02 O-RING 22.6 X 19.6 X1.5MM X 1PC;GASKET X 1PC;WASHER 12.2 X 9.1 X 0.5MM X 1PC
(COPPER); SPRING 4.9 X 3.3 X 9.5MM X 1PC; SPRING 6.5 X 5 X 25MM X 1PC; NEEDLE
CLIP X 1PC;PLYSTIC WASHER 6.8 X 3 X 0.8 X 1PCS;MAIN JET #200 X 1PC; PILOT JET #35
X 1PC; PILOT JET #30 X 1PC ;NEEDLE JET #Y279 X 1PC;FLOAT VALVE X 1PC; FLOAT
VALVE SEAT 2.5 X 1PC;AIR ADJUST SCREW X 1PC ;SLOW ADJUST SCREW X 1PC;
CHOCK VALVE X 1PCS
679440 15.95
L
SCRAMBLER
500
98-02 O-RING 20.8X23.8X1.5MM X 1PC, O-RING 3X5X1MM X 1PC, WASHER 3X5X0.5MM X
2PCS ZINC PLATE; NEEDLE CLIP X 2PCS ZINC PLATE, MAIN JET #155 X 1PC, MAIN JET
#30 X 1PC, PILOT JET #40 X 1PC, SPRING 5X 7.5MM X 1PC, NEEDLE JET Y280 X 1PC,
FLOAT VALVE X 1PC, FLOAT VALVE SEAT 1.5 X 1PC, AIR ADJUST SCREW X 1PC, RUBBER
GASKET X 1PC
679429 15.95
L
SCRAMBLER
500
SPORTSMAN
500
03-05 O-RING 20.8X23.8X1.5MM X 1PC, PLASTIC WASHER 3X6.8X2.4MM X 1PC WHITE. PLASTIC
SEAT X 1PC, NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET #155 X 1PC, MAIN JET #30 X
1PC, NEEDLE JET Y336 X 1PC, FLOAT VALVE X 1PC, FLOAT VALVE SEAT 2.0 X 1PC, PILOT
JET #40 X 1PC, RUBBER GASKET X 1PC
679430 15.95
L
SUZUKI
LT4WD
87-89 GASKET X 1, O-RING X 5,SPRINGX1,WASHER X 1 , C-CLIPX1 ,SCREW X 1,JET X 2,
NEEDLE X 2 ,TRI-NEEDLE X 1,NEEDLE JETX1 ,2.0MM FLOAT VALVEX1 ,TOTAL:18 PCS
679415 12.95
L
90-96 GASKET X 1, O-RING X 2, SPRING X 2, C-CLIPX1, WASHER X 3, JETX 3, NEEDLE X 2 , 2.0
MM FLOAT VALVE X1, SCREWX1, TOTAL: 15 PCS
679419 12.95
L
LTF250
88-89 GASKET X 1, O-RING X 5,SPRINGX1,WASHER X 1 , C-CLIPX1 ,SCREW X 1,JET X 2,
NEEDLE X 2 ,TRI-NEEDLE X 1,NEEDLE JETX1 ,2.0MM FLOAT VALVEX1 ,TOTAL:18 PCS
679415 12.95
L
90-96 GASKET X 1, O-RING X 2, SPRING X 2, C-CLIPX1, WASHER X 3, JETX 3, NEEDLE X 2 , 2.0
MM FLOAT VALVE X1, SCREWX1, TOTAL: 15 PCS
679419 12.95
L
SUZUKI
OZARK250
--- O-RING 5.6X8.8X1.8MM X 1PC, O-RING 3X5X1MM X 1PC, WASHER 3X5X0.5MM X 1PC
ZINC PLATE NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET #137.5 X 1PC,
PILOT JET #17.5 X 1PC, SPRING 8.4X 13.8MM X 1PC, SPRING 7.8X 10.6MM X 1PC,
SPRING 6.5X 27.5MM X 1PC, SPRING 5.2X 7.5MM X 1PC, NEEDLE JET Y329 X 1PC,
FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC,
NEEDLE SEAT X 1PC, AIR ADJUST SCREW SEAT X 1PC
679428 15.95
L
LTA400F
03-07 O-RING 8.8X11.8X1.5MM X 1PC, O-RING 3X5X1MM X 1PC, WASHER 3X5X0.5MM X 1PC
ZINC PLATE, WASHER 5.6X9.8X0.5MM X 1PC, ZINC PLATE
MAIN JET #122 X 1PC, MAIN JET #55 X 1PC, PILOT JET #38 X 1PC, SPRING 4.9X 13.2MM
X 1PC, SPRING 7.9X 18.9MM X 1PC, SPRING 6X 39.7MM X 1PC, NEEDLE JET D484 X 1PC,
FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC
679427 15.95
L
BRONCO ATV CARBURETOR REBUILD KITS continued
