2015 ATV / UTV CATALOG
APPLICATION YEAR DESCRIPTION
PART #
SUZUKI
CONTINUED
LT80
87-06 O-RING 12.6 X 9 X1.8MM X 1PC;5.6 X 2.8 X1.4MM X 1PC;5 X 2 X 1.5MM X 1PC;GASKET
X 2PCS;WASHER 5 X 3 X 0.5MM X 1PC;SPRING 4.9 X 3.3 X 9.5MM X 1PC;NEEDLE CLIP
X 1PC;MAIN JET #92.5 X 1PC;PILOT JET #20 X 1PC;NEEDLE JET #Y163 X 1PC;FLOAT
VALVE X 1PC;FLOAT VALVE;SEAT 2.5 X 1PC; AIR ADJUST SCREW X 1PC
679433 15.95
L
LTF500F
98-02 O-RING 5 X 3 X 1MM X 1PC;RUBBER GASKET X 1PC;WASHER 5 X 3 X 0.5MM X
1PC;WASHER 10 X 5.2 X 1.6MM X 1PC;NEEDLE CLIP X 1PC;SPRING 5.2 X 4 X 7.3MM X
1PC;MAIN JET #155 X 1PC;MAIN JET #130 X 1PC;PILOT JET #55 X 1PC ;NEEDLE JET
#Y236 X 1PC;FLOAT VALVE X 1PC;FLOAT VALVE SEAT X 1PC;AIR ADJUST SCREW X
1PC
679438 17.95
L
YAMAHA
YFM80
92-04 WASHER 3X5.2X0.5MM X 1PC ZINC PLATE ,O-RING 3X5.5X1MM X 1PC, O-RING
22X27X2.5MM X 1PC, MAIN JET #76.5 X 1PC, NEEDLE JET CLIP X 1PC, PILOT JET #12.5 X
1PC, SPRING 10 X 5MM X 2PCS, NEEDLE JET Y248 X 1PC, NEEDLE JET HOLDER X 1PC,
AIR ADJUST SCREW X 1PC, SLOW ADJUST SCREW X 1PC, M-SPRING X 1PC, FLOAT
VALVE X 1PC, GASKET 58.7 X 54MM X 1PC, GASKET 54 X 40MM X 1PC
679397 15.95
L
YFB250
92-98 GASKET X 2, O-RING X 4,SPRING X 2,C-CLIPX1 ,WASHER X 2,JETX 2,W-CLIPX1, NEEDLE
X 2 ,1.8 MM FLOAT VALVE X1 ,NEEDLE JET X 1,SCREWX1 ,TOTAL:19 PCS
679418 12.95
L
YFM250
99-04 O-RING 3X5.5X1.3MM X 1PC, PLASTIC WASHER 3X6.8X1.5MM X 1PC, PLASTIC
WASHER3.2X10X3.5/1MM X 1PC, BRASS WASHER 5.2X10X1.5MM X 1PC, MAIN JET #95
X 1PC, MAIN JET #80 X 1PC, NEEDLE JET CLIP X 1PC, PILOT JET #42.5 X 1PC, SPRING
14.5 X 8.2MM X 1PC, NEEDLE JET Y319 X 1PC, FLOAT VALVE X 1PC, FLOAT VALVE SEAT
#2.0 X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC, BOLT X 1PC, SPRING
9.7X4.8MM X1PC, WASHER 3X5.2X0.5MM X 1PC ZINC PLATE, O-RING 3X5X1MM X 1PC.
679396 15.95
L
YFM350FW 89-92 GASKETX2 PCS, O-RINGX4 PCS,SPRINGX2 PCS,WASHER X 2PCS,C-CLIPX1 PC, NEEDLE
X 3 PCS,2.5MM FLOAT VALVE X 1 PC, MAIN JET X 1 PC ,TOTAL:16 PCS
679403 15.95
L
YFM400A
KODIAK
00-04 O-RING X 3PCS, WASHER 3X5.2X0.5MM X 2PCS ZINC PLATE, MAIN JET #70 X 1PC, MAIN
JET #80 X 1PC, MAIN JET #132.5 X 1PC, PILOT JET #17.5 X 1PC, SPRING 7.5 X 5.2MM
X 1PC, NEEDLE JET Y258 X 1PC, FLOAT VALVE X 1PC, FLOAT VALVE SEAT #2.0 X 1PC,
AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC, NEEDLE JET HOLDER X 1PC,
THROTTLE STOP SREW X 1PC
679395 15.95
L
YFM400FW
BIG BEAR
00-06 O-RING 5.6X8.8X1.7MM X 3PCS, O-RING 4.5X8X1.75MM X 1PC, O-RING 3X5X1MM X 2PCS,
O-RING 15.5X19.5X2MM X 1PC, O-RING 20X24X2MM X 1PC, WASHER 4.5X10X0.7MM X
1PC GOLD PLATE, WASHER 3X6.8X0.5MM X 1PC ZINC PLATE, WASHER 3X5X0.5MM X
2PCS ZINC PLATE, PLASTIC WASHER 3X6.8X2.4MM X 1PC WHITE, NEEDLE CLIP X 1PC
ZINC PLATE, MAIN JET #112.5 X 1PC, MAIN JET #70 X 1PC, MAIN JET #80 X 1PC, PILOT
JET #17.5 X 1PC, SPRING 5X 7.5MM X 1PC, NEEDLE JET Y260 X 1PC, FLOAT VALVE X
1PC, FLOAT VALVE SEAT 2.0 X 1PC, AIR ADJUST SCREW X 1PC, RUBBER GASKET X 1PC,
NEEDLE SEAT X 1PC, AIR ADJUST SCREW SEAT X 1PC
679424 15.95
L
YFM600
GRIZZLY
98-01 O-RING 3X5X1MM X 1PC, WASHER 3X5.2X0.5MM X 1PC ZINC PLATE, WASHER
3X8X0.5MM X 1PC ZINC PLATE, NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET #1445 X 1PC,
MAIN JET #70 X 1PC, PILOT JET #42.5 X 1PC, SHORT SPRING 5X9MM X 1PC, NEEDLE JET
Y257 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, NEEDLE HOLDER X 1PC,
RUBBER GASKET X 1PC, SEAT X 1PC.
679402 15.95
L
YFM600H
GRIZZLY
HUNTING
00 O-RING 3X5X1MM X 1PC, WASHER 3X5.2X0.5MM X 1PC ZINC PLATE, WASHER
3X8X0.5MM X 1PC ZINC PLATE, NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET #1445 X 1PC,
MAIN JET #70 X 1PC, PILOT JET #42.5 X 1PC, SHORT SPRING 5X9MM X 1PC, NEEDLE JET
Y257 X 1PC, FLOAT VALVE X 1PC, AIR ADJUST SCREW X 1PC, NEEDLE HOLDER X 1PC,
RUBBER GASKET X 1PC, SEAT X 1PC.
679402 15.95
L
YFM660FW 02-08 O-RING 5.4X8.8X1.8MM X 1PC, O-RING 4.8X8.5X1.9MM X 1PC, O-RING 3X5X1MM X 1PC,
WASHER 3X5X0.5MM X 1PC ZINC PLATE, PLASTIC WASHER 3X6.8X2.4MM X 1PC WHITE.
NEEDLE CLIP X 1PC ZINC PLATE, MAIN JET #156 X 1PC, MAIN JET #55 X 1PC, MAIN JET
#60 X 1PC, PILOT JET #40 X 1PC, SPRING 3.9X 11MM X 1PC, SPRING 4.8X 8.5MM X 1PC,
NEEDLE JET Y321 X 1PC, FLOAT VALVE X 1PC, FLOAT VALVE SEAT X 1PC, AIR ADJUST
SCREW X 1PC, RUBBER GASKET X 1PC, NEEDLE SEAT X 1PC
679425 15.95
L
YFM350X 88-04 O-RING 5.6 X 3.2 X1.2MM X 1PC;5 X 3 X 1MM X 1PC;7.2 X 3.8 X 1.7MM X 1PC;45.8 X
39.8 X 3MM X 1PC;RUBBER GASKETX 2PCS; WASHER 5 X 3 X 0.5MM X 1PC;10 X5.3 X
1.5MM X 1PC;SPRING 4.9 X 3.3 X 9.5MM X 1PC;8.5 X 6.4 X 13.8MM X 1PC;NEEDLE CLIPX
1PC;MAIN JET #145 X 1PC;PILOT JET #42.5 X 1PC ;NEEDLE JET #Y218 X 1PC; FLOAT
VALVE X 1PC; FLOAT VALVE SEAT 2.5 X 1PC;AIR ADJUST SCREW X 1PC
679432 15.95
L
BRONCO ATV CARBURETOR REBUILD KITS continued
