BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
161
2015 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
HAYES 12" X 2" CENTERLINE
FAYETTE 10" x 2-1/4"
* Contained in Hardware Kit (Axle Kit)
PART #
#
DESCRIPTION
N/A
1
Actuating Lever - R.H.
N/A
1
Actuating Lever - L.H.
N/A
1
Actuating Lever - R.H.
N/A
1
Actuating Lever - L.H.
N/A
2
Magnet Kit (4.5K Axles)
N/A
2
Magnet Kit (6K & 7K Axles)
N/A
3
Return Spring Set (Axle Set)
855353
10.83
E
4
Hold Down Kit (Axle Set)
855404
11.43
E
5,6 Adjusting Screw Kit (Spring & Screw Assembly)
855605
1.60
G
7
Grease Seal (each)
855652
5.72
E
10 Grease Cap (each)
LM25580CC
14.85
L
8
Bearing Set - Inner LM25520, LM25580
LM67048CC
7.20
L
9
Bearing Set - Outer LM67048, LM67010
N/A
11 Shoe and Lining Kit
PART #
REF # DESCRIPTION
N/A
1
Actuating Lever - R.H.
N/A
1A Actuating Lever - R.H.
N/A
2
Magnet Kit
855304
8.16
E
3
Return Spring et (Axle Set)
855353*
10.83
E
4
Hold Down Kit (Axle Kit)
855404
11.43
E
5,6 Adjusting Screw Kit (Spring & Screw Assembly)
GS545138
1.60
L
7
Grease Seal (each)
GCP10
1.98
L
10 Grease Cap (each)
LM68149CC
7.45
L
8
Bearing Set - Inner LM68111, LM68149
N/A
9
Bearing Set - Outer LM44649, LM44610
TBK9
12.95
G 7,8,9,10 Bearing/Seal Kit
N/A
11 Shoe and Lining Kit
