BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
151
2015 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
PART #
647284 80.25
G
THE EASIEST TO USE ADVANCED BRAKE CONTROL AVAILABLE
AGILITY
TM
Packed with features to provide the ultimate ease
in setting and adjusting for safe, smooth stops.
Towing large trailers hinders your ability to stop quickly. Protect
your trailer and vehicle investment with the Agility
TM
trailer brake
control. Most states and provinces have specific laws requiring
brakes on trailers depending on weight or stopping distance.
Digital Sensitivity
Adjustment
5 settings for
different loads and
driving conditions
Innovative
Braking
Override
Large Digital Readout
Easy to read 5-99%
power scale
Digital Power/Gain
Easy to set, easy to
adjust stopping force
AGILITY
TM
PLUG-IN SIMPLE!
®
• Cuts installation time by hours
• Allows for quick removal
• Breaking capacity: Up to 8 trailer
brakes
The very best!
IMPULSE
TM
PLUG-IN SIMPLE!
®
• Fully digital...settings for power level (gain) with built in time-ramp
• Easy to read digital power scale from 5% to 99%
• Ability to invert digital display if desired mount is upside down
• Breaking capacity: Up to 6 trailer brakes
BRAKE-FORCE
TM
PLUG-IN SIMPLE!
®
• L.E.D. indicator shows trailer connection, braking function and short circuit notification.
L.E.D. gradually changes intensities of orange as power setting is increased
• Breaking capacity: Up to 4 trailer brakes
RELIANCE
TM
PLUG-IN SIMPLE!
®
• Fully digital...settings for power level (gain) with built in time-ramp
• Easy to read digital power scale from 5% to 99%
• Innovative vertical slide is easier to see and use than traditional
horizontal slides
• Breaking capacity: Up to 4 trailer brakes
TRAILER BRAKE CONTROLS
PART #
647294 124.00
G
PART #
647235 103.40
G
PART #
647225 69.10
G
INSIGHT™ FLEX-MOUNT™ BRAKE CONTROL
Providing the Ultimate Braking Experience!
The InSIGHT™ brake control with Flex-Mount™ versatility solves the problem of inconvenient
mounting while increasing user safety and convenience. This is achieved by bringing the display
within the driver’s line of sight and the controls within easy reach…
all with no tools required
and
Plug-In Simple!
®
installation.
• Flex-Mount™ Versatility -- Multiple mounting locations in any vehicle
• No Tools Required Installation -- Plug-In Simple!® components
• Increased User Safety -- Keeps eyes on the road and controls within easy reach
• Advanced Proportional Technology -- Mirrors braking action of the towed vehicle for safe, smooth
stops
• Digital LED Display -- Intuitive 0-99 scale of power setting
• 7 Sensitivity Settings for Advanced Braking Control
• Short Proof Protection for up to 8 Trailer Brakes
• Electric or Electric/Hydraulic Trailer Brake Compatibility
• Flex-Control™ features a soft glowing light for easy location at night
PART #
620401 151.95
G
