QUICK REFERENCE BRAKE CONTROL WIRING GUIDE
SECOND VEHICLE
MOUNTING KIT
For Impulse
TM
and
BrakeForce
TM
brake
controls
ELECTRONIC BRAKE
CONTROL INSTALLATION KIT
Everything needed to install most brake controls!
• 20 zip ties
• 4 butt splices
• 1 ring connector
• 1 splice connector
• 1 20’ amp fuse/holder
• 15’ black wire - 12 gauge
• 15’ white wire - 12 gauge
• 25’ blue wire - 12 gauge
• 3’ red wire - 16 gauge
NOTE: Locate wires on vehicle by function only. Not all vehicles are listed below. Refer to product instructions.
PART #
647685 13.95
G
PART #
647275 33.00
G
APPLICATION
YEAR PART #
LAND ROVER
LR3
05-10
647715 14.05
G
LR4
10-11
647715 14.05
G
Range Rover
05-13
647715 14.05
G
LEXUS
GX460
10-13
647815 16.80
G
GX470
03-10
647815 16.80
G
LX 570
08-13
647815 16.80
G
LINCOLN
Aviator (w/ factory 4 flat)
03-05
647715 14.05
G
Aviator (w/ factory 7 blade)
03-05
647715 14.05
G
Mark LT
07-08
647715 14.05
G
MKT
10-11
647715 14.05
G
MKT
12-13
620402 22.95
G
Navigator
98-12
647715 14.05
G
Navigator
13-14
620403 22.95
G
MERCURY
Mountaineer
02-10
647715 14.05
G
APPLICATION
YEAR PART #
NISSAN
Armada
04-13
647635 16.80
G
Frontier Pickup
04-13
647635 16.80
G
NV Van
14
647635 16.80
G
Pathfinder
04-13
647635 16.80
G
Titan
04-13
647635 16.80
G
Xterra
04-13
647635 16.80
G
RAM
Ram 1500 (w/ tow pkg)
10-12
620405 22.95
G
Ram 1500 (w/ tow pkg)
13-14
620407 22.95
G
Ram Pickup 2500/3500 (w/ tow pkg)
10-12
620405 22.95
G
SATURN
Outlook
07-10
620404 22.95
G
TOYOTA
Land Cruiser
03-10
647815 16.80
G
4-Runner
03-11
647815 16.80
G
Sequoia (w/ tow pkg) (MT)
03-13
647815 16.80
G
Tacoma
05-13
647815 16.80
G
Tundra
03-12
647815 16.80
G
PLUG-IN SIMPLE!
®
BRAKE CONTROL CONNECTORS continued
