TRAILER
BOARD
PART #
HEIGHT SIZE
CS28104 3.25
G 2-1/4" 2 x 4
CS28105 1.25
B 3-1/4" 2 x 6
ONE-
PIECE
KEEL
ROLLER
BRACKETS
ON THIS PAGE ARE THE NECESSARY PARTS TO MAKEYOUR OWN CUSTOM ROLLER KIT. ALLYOU DO IS PICK A BRACKET, A
SHAFT AND TWO PAL NUTS. FIND THE CORRECT SIZE ROLLER ON THE FOLLOWING PAGES AND ASSEMBLE THE PERFECT SIZE.
• Heavy duty one piece brackets
• which mount to cross member to
• hold roller
• For 5/8" shaft with 17/32" x 5" lot
• for adjustment
• 11 gauge steel
• Galvanized finish
ADJUSTABLE BUNK
BRACKETS
TO CREATE THE ABOVE ORDER ONE OF
EACH AND SIMPLY BOLT THE ANGLE
BRACKET TO THE SUPPORT BRACKET.
PART #
HOLE CENTERS
CS10200 2.20
G
2-1/2" on center
CS10201 2.20
G
2" on center
BOLSTER SUPPORT
BRACKETS
• Zinc plated
• Heavy 11 gauge steel
with double slot for
vertical adjustment
• Non-slip dimples for
• better hold
• Width: 2-1/2"
• Slot Width: 17/32"
• Galvanized
bracketwill adjust
vertically to hold
2" bunks on edge
• Width: 2", double
slots
PART#
LENGTH
EACHSLOT
CS10600 7.55
G
9-1/2"
7/16" x 6"
CS10601 10.80
G
12-5/8" 17/32" x 9-1/8"
SWIVEL/BOLSTER
BRACKET
• Zinc plated
• Heavy gauge steel brackets
mount 2" bunks on edge
• Slotted vertical adjustment to
standard or deep V-hulls
• Width: 2"
• Slot 17/32"
PART #
EACH SLOT
CS10604 8.20
G 7/16" x 2-1/2"
PART #
LENGTH EACH SLOT
CS10100 6.50
G
9"
2-3/4"
CS10101 9.25
G
11"
3-3/4"
CS10102 10.55
G
13"
4-3/4"
SWIVEL ANGLE
BRACKET
• Zinc plated
• For use with bolster brackets to secure tie
downs
PAL NUTS
PART #
SIZE
690188 0.45
E
1/2"
690190 0.50
G
5/8"
• Zinc plated push on to secure
• rollers to shaft
• Push on metal cap
• 2 sizes
• Sold each (bulk)
SPLIT TWO-PIECE
KEEL ROLLER
BRACKETS
PART # CS10500 15.70
G
• Two piece brackets to
• accommodate any length roller
• 17/32" x 5" slot for vertical
• adjustment
• 11 gauge steel
• Zinc plated - 5/8" shaft
• Sold in pairs only
SLOT
PART #
ROLLER CNTR.
CS10300 14.20
G
4"
2"
CS10301 14.95
G
5"
3"
CS10303 19.40
G
8"
6"
CS10304 20.55
G
10"
8"
CS10305 22.10
G
12"
10"
ZINC PLATED
ROLLER SHAFTS
BOLSTER/SWIVEL
BRACKET
ASSEMBLIES
VERTICAL BUNK
BRACKETS
ASSEM.
PART #
LENGTH SLOT CTN
CS10000 11.95
G 9" 2-3/4" 48
CS10001 13.95
G11" 3-3/4" 36
CS10002 15.95
G13" 4-3/4" 36
• 2-1/2" width
• Bunk mount holes
2-1/2"on center
PART #
DESCRIPTION
CS10003 14.60
G
Assembled bracket, bulk
CS10101 9.25
G
Bracket only
• Sold each (bulk)
PART #
LENGTH DIA.
CS10700 5.10
G
5-1/4" 1/2"
CS10701 5.25
G
6-1/4" 1/2"
CS10704 1.38
H
4-5/8" 1/2"
CS10705 8.95
G
12-3/4" 1/2"
CS10721 1.80
H
5-1/4" 5/8"
CS10722 6.10
G
6-1/4" 5/8"
CS10725 6.95
G
9-1/4" 5/8"
CS10726 7.75
G
11-1/8" 5/8"
CS10727 8.50
G
13-1/2" 5/8"
ROLLER BUNK MOUNTING BRACKET
• Galvanized swivel top bracket provides
vertical and tilting adjustment for roller bunks
• Mount on trailer cross member
• Non-slip dimples for security
• Pair of bunks requires at least 4 brackets
• Slots: 17/32" x 3-3/4"
• Width: 2-1/2"
• Assembled length: 11"
STATIONARY BUNK
BRACKETS
• Zinc Plated
• U-brackets mount on top of
trailer cross members to hold
2" x 4" bunks on edge
• Made of 10 gauge steel
TAILLIGHT
BRACKETS
• Galvanized brackets to
hold trailer side rail
• Punched to hold lights
and wiring
CS26057
3.15
G
1-1/2” wide
8-1/2” long
