Carpeted bunkboards provide proper center loading in wind or side current conditions • 2" x 4" x 5 Ft. boards tilt and
are covered with high grade marine carpet • Distance between galvanized upright posts can be adjusted to fit trailer
• Can be mounted on top of frame for extra height • Complete in display box • Height: 21" • Adjust: out to 13"
each side • Fits: Frame up to 3" W x 4-1/4" H • Tube: 1-1/2" sq. 16 ga. • Matl: Pre-galvanized steel • Angle: 75
o
JON BOAT FRONT SUPPORT BUNK
BLACK CARPET INSTALLED
Carpeted 2" x 24" bunk
cushions and suppor ts
front of jon boat or other flat
bottom boat • Adjusts from
5-1/2" to 8" above tongue •
Place on tongue at proper
length for boat • Brackets
are hot dipped galvanized
• Complete with mounting
hardware for 2" or 3" tongue
BUNK BOARD GUIDE-ON
BLACK CARPET INSTALLED
CS27600 182.95
G
Sold Per Pair Boxed
SHORT BUNK STYLE BOAT
GUIDE-ON
Same solid construction as our larger model • Bunk is 24" long, covered with deluxe marine carpet, and mounted
with an extra strong adjustable bracket • Can be mounted on top of frame for extra height • Complete in display
box • Height: 21" • Adjust: out to 13" each side • Fits: Frame up to 3" W x 4-1/4" H • Tube: 1-1/2" sq. 16 ga.
Matl: Pre-galvanized steel • Angle: 75
o
BLACK CARPET INSTALLED
FOR BOTH STYLES
Use kit #
CS11416
longer u-bolts
for frames up to 3" x 5-1/4"
Use kit #
CS27630
for raised mounting
of tail lights
CS27660 159.95
G
Sold Per Pair Boxed
CS27850 56.15
G
Sold Per Pair Boxed
Makes boat loading easier • Galvanized posts are pre-assembled with 9" roller
and end caps • Can be mounted on top of frame for extra height • Complete in
display box • Height: 21" • Adjust: out to 13" each side • Fits: frame up to 3"
W x 4-1/4" H • Post: 1-1/2" sq. 16 ga. • Matl: pre-galvanized steel • Angle: 90
o
ROLLER GUIDE-ON
REPLACEMENT PARTS
PART #
DESCRIPTION MEASUREMENTS
690126 7.60
G Roller
2" x 9"
690160 2.15
G End Cap 2" x 1-3/4"
CS10705 8.95
G Shaft
1/2" x 12-3/4"
690188 0.45
E Cap Nut
1/2"
ROLLERS ALREADY PRE-ASSEMBLED TO POSTS
FITS INSIDE 2" PVC PIPE
PART #
DESCRIPTION
CS27656A 36.70
G
LED
Top Light Kit For Post Guides, Packaged
LONGER U-BOLT KIT
FOR FRAMES UP TO 3" WIDE X 5-1/4" HEIGHT
• Longer u-bolts to mount all styles of boat guides on taller trailer
frames up to 5-1/4" in height
• Leg length is 6" with thread length of 2"
• 5' bunkboard style guide-on requires 2 sets, all other guide-ons
require 1 set
GUIDE-ON LIGHT BRACKETS
FOR 40" AND 60" POST STYLE
FOR BUNKBOARD, SHORT BUNK, AND ROLLER STYLE
• Mounts lights out from PVC post approx. 7-1/2"
• Includes 2 formed galvanized brackets, 2 pieces
of color coded 3-conductor bonded wire, 8 ft.
length each, 4 terminals and 4 butt connectors
plus hardware for mounting to PVC posts (does not include lights)
• Mount tail lights high and dry
• Includes 2 2-3/4" x 6" galvanized brackets plus
hardware for mounting to pre-punched boat guide-
on upright posts (does not include lights or wiring)
PART # CS27610 153.25
G
Sold Per Pair
CS11416 19.95
G
Sold Per Kit Set of 4 U-bolts
CS27650 42.40
G
Sold Per Kit
CS27630 22.05
G
Sold Per Kit
• Add a pair of these amber and red
lamps on top of your existing post
guide-ons and see your trailer's
position clearly as you back up
TOP LIGHT KIT FOR POST STYLE
BOAT GUIDES - LED
