TOWING & LOADING
209
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
Boat Guides' Extra Height Improves
Visibility When Launching or Backing Up
Easy On and
Off the Trailer
BOAT GUIDES TRAILER POSITIONERS
For quick, easy boat centering, in and out of the water • Ideal for boat lifts and trailers
• Simple design - no moving parts to corrode, hang up or damage your boat • Fully
adjustable for all popular trailers • Easy installation - no drilling required • Non-marring
white finish for high visibility • Extra long mounting hardware fits all popular trailers and
boat lifts • Trailer lights can be kept out of the water by attaching boat guides
PART #
DESCRIPTION
FT158
98.89
E
44" Boat Guides with Hardware - Boxed for Display
FT160
104.63
E
50" Boat Guides with Hardware - Boxed for Display
PART #
SIZE
CS11035 1.50
AD 3/8" - 16 x 3"
PART #
SIZE
CS10921 0.99
J 7/16" - 14 x1"
#14 PAN HEAD PHILLIPS
TAPPING SCREWS
• Packs of 8 screws
• Usually used to attach
vertical or horizontal wooden
bunks to bunk brackets
• Display packages of 4 bolts,
washers and nuts
• Zinc plated steel, grade 2
• Can be used to mount
fenders to fender brackets
MOST TRAILER MANUFACTURERS USE GRADE 5 SCREWS AND BOLTS FOR MAXIMUM SAFETY AND SECURITY. GRADE 5
HARDWARE HAS A HIGHER TENSILE STRENGTH THAN THE GRADE 2 HARDWARE USUALLY FOUND IN HARDWARE STORES.
• Packs of 4 zinc plated star-
shaped pyramidal type washers
used with U-bolts for heavy duty applications
• Gripping teeth have high holding strength
and will withstand extreme torques
• Packs of 4 bolts, washers and nuts
• Zinc plated steel, grade 5
• Can be used to mount
brackets, coupler and
winch stands
PART #
SIZE
CS11006 0.99
J
14 x 3/4"
PYRAMIDAL TYPE
WASHERS
PART #
SIZE
CS10806 2.40
G 7/16"
CS10805 2.40
G 3/8"
3/8" - 16 SLOTTED
TRUSS HEAD BOLTS
• Packs of 4 bolts, washers
and nuts
• Zinc plated steel, grade 5
• Used to mount tongue to
trailer frame
HEX HEAD BOLTS
PART #
SIZE
CS10941 3.75
J
3/8" - 16 x 3/4"
• Deluxe, high quality, weather-resistant carpet renews trailer bunk appearance and protects boats from scratches
• Durable backing with minimal water retention
• Width of 10" will completely surround 2" X 4" bunk
• Black only
PART #
LENGTH
CS27800 26.90
G
3 Ft.
CS27810 40.45
G
4 Ft.
CS27820 54.00
G
5 Ft.
HEAVYDUTYCARPETEDBUNKBOARDS
REPLACEMENT CARPET
CS11330 21.95
G
11" x 12 Ft. Boxed
• Marine grade 2" X 4" bunks covered with top quality, weather-resistant marine carpet (black) to protect hulls from
scratching when launching, loading or trailering
• Long-lasting black carpet has minimal water
retention, durable backing
ROLLER BUNKS
• Change bunk trailers to roller type
• Channel-style bunks pre-assembled
• Pair supports up to 1,500 lbs.
• Made of heavy gauge galvanized steel for long lasting rust protection
• Can be mounted on existing flat bunkboards, or used with our special mounting brackets
(sold separately) for height and angle adjustment
• No hardware is included
• Channel: 2-1/8" W x 2-1/2" H
PART #
LENGTH
ROLLERS
CS27700 184.95
G
4'
5
CS27710 219.95
G
5'
6
• Sold in pairs, boxed
• Sold in pairs
HEX HEAD BOLTS
