DESCRIPTION
YEAR
PART #
POLARIS
CONTINUED
500 RANGER & RANGER CREW 2011 THE 2011 500 HAS SMALL BODY STYLE AND FRONT MCPHER-
SON STRUTS LIKE THE 400 AND IS NOT A FULL SIZE RANGER LIKE THE 2011 800
11
4525007 49.95
B
500 RANGER 2X4, 4X4
04-08
4525007 49.95
B
700 RANGER 2X4, 4X4
06-08
4525007 49.95
B
ALL POLARIS ATVS WITH MCPHERSON STRUTS
96-11
4525007 49.95
B
NOTE: POLARIS “FRONT ONLY”LIFT KIT- FOR 500/700 RANGER SEE APPLICATIONS BELOW& ALL POLARIS ATVS 96-11 WITH MCPHERSON STRUTS
570 RANGER MIDSIZE
14-15
4588517 TBA
570 RANGER CREW MIDSIZE
14-15
4588517 TBA
NOTE: FITS MIDSIZE MODELS ONLY; DOES NOT FIT 570 FULL SIZE RANGER MODELS
570 RZR
12-14
254039 169.95
SPORTSMAN 570 SP
15
4588518 TBA
600 4X4 SPORTSMAN
03-05
4527000 119.95
B
700 4X4 SPORTSMAN
02-06
4527000 119.95
B
700 EFI 4X4 SPORTSMAN
05-06
4527000 119.95
B
500 & 700 I.R.SEFI RANGERS
06-08
4527001 119.95
B
700 I.R.S. RANGER CREW
08-09
4527001 119.95
B
BOBCAT 3200 2X4
11-12
4527001 119.95
B
BOBCAT 3400 4X4
11-12
4527001 119.95
B
BOBCAT 3400XL 4X4
11-12
4527001 119.95
B
BOBCAT 3450 4X4 2011-2012 RAPID LINK SYSTEM FOR ATTACHMENTS
11-12
4527001 119.95
B
DOES NOT FIT ANY NEW BODY STYLE 2009 RANGER OR THE 2010 RANGER CREW
DOES NOT FIT THE STRAIGHT AXLE POLARIS RANGERS
THIS KIT ONLY FITS THE INDEPENDENT REAR SUPSENSION MODELS
500 EFI RANGER 09-10 FULL SIZE DOES NOT FIT 2011
09-10
254004 141.95
B
700 EFI RANGER XP & HD IRS 2009 FULL SIZE DOES NOT FIT 2009 RANGER 700 CREW
09
254004 141.95
B
800 EFI RANGER XP, HD IRS FULL SIZE
10-13
254004 141.95
B
800 EFI RANGER CREW IRS FULL SIZE
10-14
254004 141.95
B
NOTE: 1.5” SPACERS ARE RECOMMENDED, BUT A MINIMUM OF A 1” WHEEL SPACER IS REQUIRED ON THE FRONT IF YOU ARE RUN-
NING 12” DIAMETER FACTORY OR AFTERMARKET WHEELS FOR THE WHEEL TO CLEAR THE TIE ROD WITH THE ALIGNMENT CONES
INSTALLED. IF YOU ARE RUNNING WIDE TIRES A 1.5” OR WIDER SPACER MAY BE REQUIRED DEPENDING ON THE WIDTH OF THE
TIRE FOR TIRE TO SHOCK CLEARANCE AT FULL LOCK STEERING.
NOTE: IF YOU HAVE UPGRADED OR PLAN TO UPGRADE TO OUR PRO SERIES TIE ROD/RACK END KIT YOU WILL NEED OUR PART#
PSAK-1 ALIGNMENT CONE KIT FOR 1/2” DIAMETER BOLTS. OUR PSAK-1 ALIGNMENT KIT COMES WITH 2- ALIGNMENT CONES AND
ALL OF THE HARDWARE REQUIREDTO UPGRADE BOTH SIDES OFYOUR RANGER AND IS USEDTO HELP CORRECTYOURTIE ROD ANGLES.
NOTE: BE SURE TO ASK IF THE CUSTOMER HAS OUR HIGH LIFTER FORWARD A-ARM KIT THAT NOW INCLUDES OUR PSAK-1 ALIGN-
MENT CONE KIT FOR 1/2” BOLTS. IF THEY DO THEY CAN INSTALL OUR HD RANGER TIE ROD KIT WITH NO ADDITIONAL PURCHASES.
NOTE: NEW “REAR” DHT AXLES, HLP PRO SERIES OR GORILLA CV AXLES ARE RECOMMENDED FOR THE 2011-2014 RANGER
BEFORE INSTALLING OF ANY BRAND OF LIFT KIT. THE 2011-2014 MODEL RANGERS HAVE LIGHTER DUTY REAR AXLES THAN PRE-
VIOUS YEAR MODELS AND ARE MORE PRONE TO BREAKAGE. ALL CUSTOMERS SHOULD BE AWARE OF THESE RISKS BEFORE
INSTALLING A LIFT KIT ON A 2011-2014 RANGER, AS HIGH LIFTER WILL NOT WARRANTY OR REPLACE ANY BROKEN CV AXLES.
SPORTSMAN 400 2012-2014 -REAR AXLE BAR KIT ABK-P-2, REAR PRO SERIES AXLES OR REAR
GORILLA AXLES ARE REQUIRED ON MODELS
12-14
4525004 174.95
B
SPORTSMAN 450
06-08
4525004 174.95
B
SPORTSMAN 500 2005 BUILT AFTER 1/1/2005 ONLY
05
4525004 174.95
B
SPORTSMAN 500
06-10
4525004 174.95
B
SPORTSMAN 500 2011-2013 -REAR AXLE BAR KIT ABK-P-2, REAR PRO SERIES AXLES OR REAR
GORILLA AXLES ARE REQUIRED ON 2011-2014 MODELS
11-13
4525004 174.95
B
SPORTSMAN 570 2014-2015 NON SP EDITION-REAR AXLE BAR KIT ABK-P-2, REAR PRO SERIES AXLES
OR REAR GORILLA AXLES ARE REQUIRED ON 2014 MODELS
14-15
4525004 174.95
B
SPORTSMAN 600 2005 BUILT AFTER 1/1/2005 ONLY
05
4525004 174.95
B
SPORTSMAN 700 2005 BUILT AFTER 1/1/2005 ONLY
05
4525004 174.95
B
SPORTSMAN 700
06-07
4525004 174.95
B
SPORTSMAN 800 2005 BUILT AFTER 1/1/2005 ONLY
05
4525004 174.95
B
SPORTSMAN 800 EFI
06-10
4525004 174.95
B
SPORTSMAN 800 2011-2014- REAR AXLE BAR KIT ABK-P-2, REAR PRO SERIES AXLES OR REAR
GORILLA AXLES ARE REQUIRED ON 2011-2015 MODELS
11-14
4525004 174.95
B
NOTE:BE SURE TO ALWAYS CHECK CV BOOT CLEARANCE AT STRUT HOUSING DURING INSTALLATION ASYOU MAY HAVE TO GRIND
ALUMINUM STRUT HOUSING TO CREATESUFFICIENT CLEARANCE FOR CV BOOTS EVEN IF YOU ARE RUNNING STOCK CV AXLES
WE HAD TO CLEARANCE THE STRUT HOUSING ON THE 2011 MODEL SPORTSMAN WE TESTED WITH FACTORY AXLES. IF YOU ARE
RUNNING A PRO SERIES OR GORILLA AXLE YOU WILL HAVE TO CLEARANCE THE STRUT HOUSING.
NOTE:FOR LIFT KIT TO WORK ON ANY 2005 MODEL SPORTSMAN IT “MUST” BE BUILT AFTER THE 1/01/2005 DATE
NOTE: THIS KIT DOES NOT FIT THE POLARIS X2 MODELS
NOTE: THIS KIT DOES NOT WORK ON POLARIS SPORTSMAN 570 SP 2015.SEE NEW KIT FOR SPORTSMAN 570 SP
INSTALLATION NOTES FOR 2011-2015 MODELS:
*ON 2011-2015 MODELS THE CUSTOMER MUST UPGRADE TO A HLP REAR AXLE BAR REPLACEMENT KIT ABK-P-2 OR UPGRADE
THE REAR FACTORY CV AXLES WITH HLP PRO SERIES AXLES OR GORILLA AXLES ON 2011-2012 MODELS WITH A LIFT KIT
INSTALLED THE REAR AXLES BIND WHEN THE SUSPENSION IS AT FULL EXTENSION /DROOP AND ARE SUBJECT TO BREAK.
HIGH LIFTER ATV LIFT KITS continued
