2015 ATV / UTV CATALOG
DESCRIPTION
YEAR
PART #
POLARIS
CONTINUED
RANGER RZR 800 2007-2008 DOES NOT FIT 2009 MODELS
07-08
4528003 129.95
B
800 RZR 2009-2013 DOES NOT FIT RZR “S” OR RZR “4” MODELS
09-13
4528004 129.95
B
NOTE: REAR AXLE BAR KIT ABK-P-3, REAR PRO SERIES AXLES OR REAR GORILLA AXLES ARE REQUIRED ON 2011-2013 MODELS
800 RZR “S” 2009-2014
09-14
254040 269.95
B
800 RZR “4”
10-14
254040 269.95
B
550/850 SPORTSMAN XP, X2 and TOURING
09
4528501 499.95
A
550/850 SPORTSMAN XP, X2 AND TOURING
* REAR FACTORY UPPER A-ARM MODIFICATION REQUIRED-SEE NOTES BELOW
10
4528501 499.95
A
POLARIS 550/850/1000 SPORTSMAN XP AND TOURING 2011-2015
* REAR FACTORY UPPER A-ARM MODIFICATION REQUIRED
* CUSTOMER MUST UPGRADE TO A HLP FRONT AXLE BAR REPLACEMENT KIT ABK-P-1, OR UPGRADE THE FRONT FACTORY CV
AXLES WITH HLP DHT AXLES, HLP PRO SERIES AXLES OR GORILLA AXLES -SEE NOTES BELOW
POLARIS 850 SCRAMBLER XP HO AND SCRAMBLER 850 XP HO EPS 2013-15
* ON 2013-15 SCRAMBLER CURRENTLY YOU DO NOT NEED TO CLEARANCE THE REAR FACTORY UPPER A-ARM WITH “FACTORY”
AXLES, BUT IF YOU DO UPGRADE TO AN AFTERMARKET AXLE LIKE A HLP DHT, PRO SERIES OR GORILLA AXLE YOU WILL NEED
TO REMOVE AND CLEARANCE THE REAR FACTORY UPPER A-ARM.
* FOR 2013-2015 SCRAMBLER CUSTOMER MUST UPGRADE TO A FRONT AXLE BAR REPLACEMENT KITABK-P-1, OR UPGRADE THE
FRONT FACTORY CV AXLES WITH HLP DHT AXLES, HLP PRO SERIES AXLES OR GORILLA AXLES ON SCRAMBLERS WITH A LIFT
KIT INSTALLED THE FRONT AXLES BIND WHEN THE SUSPENSION IS AT FULL EXTENSION/DROOP AND ARE SUBJECT TO BREAK.-
SEE NOTES BELOW
NOTE: THIS KIT DOES NOT FIT ANYSPORTSMAN OR SCRAMBLER MODEL WITH FOX, WALKER EVANS OR ANYBRAND OF RESER-
VOIR SHOCKS
INSTALLATION NOTE FOR “2010” SPORTSMAN 550/850:
*FOR 2010 MODEL 550/850 SPT. MODELS YOU MUST REMOVE THE REARUPPER FACTORY A-ARM AND CLEARANCE A SMALL SEC-
TION OF THE FACTORY A-ARM AS SHOWN IN OUR INSTALLATION INSTRUCTIONS TO ALLOW ADEQUATE CLEARANCE FOR THE
AXLE BOOT.
INSTALLATION NOTES FOR “2011-15” SPT 550/850/1000:
*ON 2011-15 550/850/1000 SPT. MODELS CUSTOMER MUST UPGRADE TO A HLP FRONT AXLE BAR REPLACEMENT KIT ABK-P-1,
OR UPGRADE THE FRONT FACTORY CV AXLES WITH HLP DHT AXLES, HLP PRO SERIES AXLES OR GORILLA AXLES ON 2011-2014
MODELS WITH A LIFT KIT INSTALLED THE FRONT AXLES BIND WHEN THE SUSPENSION IS AT FULL EXTENSION/DROOP AND ARE
SUBJECT TO BREAK.
*FOR 2011-15 550/850/1000 SPT. MODELS YOU ALSO MUST REMOVE THE REAR UPPER FACTORY A-ARM AND CLEARANCE A
SMALL SECTION OF THE FACTORY A-ARM TO ALLOW ADEQUATE CLEARANCE FOR THE AXLE BOOT.
INSTALLATION NOTES FOR 2013-2014 SCRAMBLER 850 XP:
*FOR 2013-15 SCRAMBLER CUSTOMER MUST UPGRADE TO A HLP FRONT AXLE BAR REPLACEMENT KITABK-P-1, OR UPGRADE
THE FRONT FACTORY CV AXLES WITH HLP DHT AXLES, HLP PRO SERIES AXLES OR GORILLA AXLES ON 2013 SCRAMBLERS
WITH A LIFT KIT INSTALLED THE FRONT AXLES BIND WHEN THE SUSPENSION IS AT FULL EXTENSION/DROOP AND ARE SUBJECT
TO BREAK.
*ON 2013-15 SCRAMBLER CURRENTLY YOU DO NOT NEED TO CLEARANCE THE REAR FACTORY UPPER A-ARM WITH “FACTORY”
AXLES, BUT IF YOU DO UPGRADE TO AN AFTERMARKET AXLE LIKE A HLP DHT, PRO SERIES OR GORILLA AXLE YOU WILL NEED
TO REMOVE AND CLEARANCE THE REAR FACTORY UPPER A-ARMTO ALLOW ADEQUATE CLEARANCE FOR THE AXLE BOOT.
SPORTSMAN XP, X2, TOURING 550/850/1000
09-15
4588519 TBA
SCRAMBLER 850/1000
13-15
4588519 TBA
900 RANGER XP 2 SEATER 2” LIFT KIT
13-15
250409 139.95
B
900 RANGER XP CREW/4 SEATER 2” LIFT KIT
14-15
250409 139.95
B
NOTE: 1.5” SPACERS ARE REQUIRED IN THE REAR IF YOU ARE RUNNING FACTORY 900 RANGER STEEL WHEELS
NOTE:IF RUNNING FACTORY RANGER 900 ALUMINUM WHEELS OR AFTERMARKET ALUMINUM WHEELS THEN SPACERS ARE NOT
REQUIRED.
900 RANGER XP 2 SEATER
13-15
254043 159.95
B
900 RANGER XP CREW/4 SEATER
14-15
254043 159.95
B
NOTE: 1.5” SPACERS ARE REQUIRED IN THE REAR IF YOU ARE RUNNING FACTORY 900 RANGER STEEL WHEELS
NOTE:IF RUNNING FACTORY RANGER 900 ALUMINUMWHEELS OR AFTERMARKET ALUMINUMWHEELS THEN SPACERS ARE NOT REQUIRED.
900 RZR XP
11-14
254041 384.95
B
900 RZR XP “4”
12-14
254041 384.95
B
HIGH LIFTER ATV LIFT KITS continued
