DESCRIPTION
YEAR
PART #
POLARIS
CONTINUED
NOTE: YOU CANNOT INSTALL THIS LIFT KIT ON ANY WALKER EVANS EDITION RZR 900 XP IF YOU ARE ALSO RUNNING THE FRONT
HIGH LIFTER OR EMP RZR900 XP BUMPER. THE LIFT WORKS FINE IF THE CUSTOMER DOES NOT HAVE A BUMPER INSTALLED ON
THEIR WALKER EVANS EDITION RZR900 XP.
NOTE: THIS NEW KIT GIVES YOU THE OPTION OF RUNNINGYOUR STANDARD RZR 900 XP 2 SEATER MODELS NON WALKER EVANS
EDITIONS IN THE 5” LIFTED POSITION FOR OPTIMAL GROUND CLEARANCE OR YOU CAN CHANGE BACK TO THE STOCK HEIGHT
LOCATION ON THE LIFT BRACKETS FOR HARDCORE TRAIL RIDING WITHOUT HAVING TO REMOVE YOUR LIFT KIT FROM YOUR 900
XP. PLEASE NOTE THIS KIT IS NOT ADJUSTABLE ON 2012-2014 XP “4” OR ANY 2 SEATER WALKER EVANS EDITON RZR900 XP DUE TO
THE LARGER SHOCK BODY ON THE WALKER EVANS EDTIONS
SEE OUR INSTRUCTIONS FOR FULL DETAILS ON THE INSTALL AND 5” LIFT/STOCK HEIGHT OPTIONS.
NOTE: SOME GRINDING ON REAR TRAILING ARM IS REQURED FOR FACTORY CV BOOT CLEARANCE.THIS IS DETAILED AND SHOWN
IN OUR INSTRUCTIONS. IF YOU ADD AN AFTERMARKET AXLE LIKE A GORILLA AXLE YOU WILL HAVE TO GRIND A LARGER PORTION
DUE TO THE LARGER DIAMETER
OUTER CUP/CV BOOT.
NOTE: THIS KIT IS ONLY ADJUSTABLE ON THE 2011-2014 RZR 900 XP STANDARD CAB 2 SEAT MODEL.
NOTE: THIS KIT IS NOT ADJUSTABLE ON THE 2012-2014 RZR 900 XP “4” 4 SEAT MODEL OR ANY 2 SEATER WALKER EVANS EDITON
RZR 900 XP DUE TO THE LARGER SHOCK BODY ON THE WALKER EVANS EDTIONS
NOTE: OUR NEW PLK900RZR-51 ADJUSTABLE KIT DOES ALLOW YOU TO INSTALL THE HIGH LIFTER OR EMP RZR 900 XP FRONT
WINCH BUMPER WITHOUT CLEARANCE ISSUES ON THE BUMPER BRACKETS ON THE STANDARD RZR900 XP 2 SEATER MODELS
NON WALKER EVANS EDITONS. YOU MUST ROTATE THE SHOCK RESERVOIR 180 DEGREES FOR PROPER INSTALLATION AND
CLEARANCES ON ALL OF THE STANDARD RZR 900 XP 2 SEATER MODELS. SEE OUR LIFT KIT INSTRUCTIONS FOR DETAILS ON
ROTATING SHOCK RESERVOIR.
NOTE: YOU CANNOT INSTALL BUMPER-RZR9 ON ANY WALKER EVANS EDITION MODELS 2 OR 4 SEATERS WITH THIS LIFT KIT
INSTALLED
NOTE: WE RECOMMEND A SET OF OUR MAX CLEARANCE RADIUS BARS...THEY OFFER MAJOR UPGRADES IN QUALITY AND A SIG-
NIFICANT GAIN IN GROUND CLEARANCE...THEY ARE A MUST FOR EVERY 900 XP. SEE PART# PSRA-RZR9 ALSO SEE OUR MATCH-
ING TOP HD RADIUS BARS...PART# PSRA-RZR9-1
NOTE: THE NEW 2011-2014 POL. 900 RZR XP IS A VERY POWERFUL MACHINE AND IS SUBJECT TO BREAK AXLES FRONT AND REAR
WITH OR WITHOUT A LIFT KIT AND BIG AGGRESSIVE TIRES. FRONT AND REAR AXLES ARE SUBJECT TO BREAK WITH OR WITHOUT
A LIFT KIT, BUT THE REAR AXLES ARE ESPECIALLY SUBJECT TO BREAKAGE WHEN ACCELERATING HARD IN REVERSE WHILE YOU
ARE STUCK, IN A BIND....ETC. AND THE SUSPENSION IS AT FULL OR CLOSE TO FULL EXTENSION.
900 RZR “S” 60” MODELS
15
4588520 TBA
NOTE: DOES NOT FIT 2015 RZR 900 50” OR 55” MODELS
SUZUKI
250 OZARK 2X4
02-07
4572500 79.95
B
400 EIGER 2X4, 4X4
02-07
4574000 137.95
B
500 QUADRUNNER MANUAL SHIFT
98-00
4575000 89.95
B
500 QUADMASTER AUTOMATIC
00-01
4575001 89.95
B
500 QUADRUNNER MANUAL
01
4575001 89.95
B
500 VINSON
02-07
254003 142.95
B
FACTORY TIE ROD ENDS ARE TO BE RE-USED IF THEY ARE IN GOOD WORKING CONDITION. IF THEY ARE NOT IN GOOD WORKING
CONDITION THEY WILL NEED TO BE REPLACED
450I KING QUAD
06-09
457700 89.95
B
700I KING QUAD
05-07
457700 89.95
B
750I KING QUAD
08-10
457700 89.95
B
NOTE: THE SUZUKI 450I, 700I & 750I KING QUAD REQUIRE A1” OR GREATER WHEEL SPACER IN THE REAR WHEN USING FACTORY
WHEELS WITH A LIFT KIT INSTALLED. NO WHEEL SPACER IS REQUIRED WHEN USING AFTERMARKET WHEELS WITH A POSITIVE
OFFSET.
500I KING QUAD
11-13
254042 159.95
B
750I KING QUAD
11-14
254042 159.95
B
NOTE: THE SUZUKI 450I, 700I & 750I KING QUAD REQUIRE A1” OR GREATER WHEEL SPACER IN THE REAR WHEN USING FACTORY
WHEELSWITH A LIFT KIT INSTALLED. NOWHEEL SPACER IS REQUIREDWHEN USING AFTERMARKETWHEELSWITH A POSITIVE OFFSET.
YAMAHA
250 TIMBERWOLF 4X4
95-99
254063 149.95
B
TIMBERWOLF 450 4X4
95-99
254063 149.95
B
250 BEAR TRACKER
94-04
254064 149.95
B
250 BRUIN
04-06
254064 149.95
B
HIGH LIFTER ATV LIFT KITS continued
