BUMPERS & WINCHES
WINCH SERVICE KITS
KIT #
ITEMS IN KIT
WR73900 168.00
G 1, (2) 20
WR69637 6.30
G (2) 2
WR74925 25.90
G 3, 7, 12, (2) 29, 31
WR74995 25.70
G 4, 5
WR74922 48.26
G 6
WR74997 22.60
G 8
WR74920 21.80
G (2) 10, (4) 19, 22
WR74917 47.40
G 9, 11, (2) 19
WR75005 32.20
G 13
WR75004 32.20
G 14
WR74918 37.40
G 15
WR75002 32.20
G 16
WR74999 30.00
G 17
WR74919 119.20
G 23, 24, 25, 26, 27, 28, (2) 29,
(2) 30, 31, 33, (6) 33, 34, 35, 36
WR74921 37.20
G 35, 37
WR74923 53.50
G 24, 25, 26, 27, 28, 31
WR74926 42.90
G 15, 30, 34
WR74930 21.50
G (2) 20, (6) 21
WR74916 16.80
G 22
WARNWINCH PARTS BREAKDOWN
RT25 & XT25
WIRE ROPE ASSY, 3/16” X 50FT
WR60076 52.10
G
SYNTHETIC ROPE KIT, 3/16”, W/FAIRLEAD
WR72128 123.50
G
SYNTHETIC ROPE KIT, 3/16”
WR73599 83.80
G
CONTACTOR, 12 VDC
WR63070 98.60
G
REMOTE CONTROL, 10FT LEAD
WR64849 64.30
G
SOCKET ASSEMBLY, REMOTE CONTROL
WR69648 41.60
G
ROLLER FAIRLEAD KIT
WR28929 45.90
G
PLATE, FAIRLEAD MOUNT
WR69901 21.50
G
HOOK KIT, 5/16” CLEVIS W/STRAP
WR39557 15.60
G
STRAP, HOOK
WR69645 4.68
G
SWITCH KIT, MINI ROCKER
WR64851 52.80
G
REMOTE CONTROL, WIRELESS
N/A
CLUTCH SEAL KIT W/SNAP RING
WR80686 24.90
G
DISC BRAKE ASSEMBLY
WR80691 51.40
G
RT30 & XT30
WIRE ROPE ASSY, 3/16” X 50FT
WR60076 52.10
G
SYNTHETIC ROPE KIT, 3/16”, W/FAIRLEAD
WR72128 123.50
G
SYNTHETIC ROPE KIT, 3/16”
WR73599 83.80
G
CONTACTOR, 12 VDC
WR63070 98.60
G
REMOTE CONTROL, 10FT LEAD
WR64849 64.30
G
SOCKET ASSEMBLY, REMOTE CONTROL
WR69648 41.60
G
ROLLER FAIRLEAD KIT
WR28929 45.90
G
PLATE, FAIRLEAD MOUNT
WR69901 21.50
G
HOOK KIT, 5/16” CLEVIS W/STRAP
WR39557 15.60
G
STRAP, HOOK
WR69645 4.68
G
SWITCH KIT, MINI ROCKER
WR64851 52.80
G
REMOTE CONTROL, WIRELESS
N/A
CLUTCH SEAL KIT W/SNAP RING
WR80686 24.90
G
DISC BRAKE ASSEMBLY
WR80691 51.40
G
WINCH SERVICE KITS
KIT #
ITEMS IN KIT
WR73900 168.00
G 1, (2) 20
WR69637 6.30
G (2) 2
WR74925 25.90
G 3, 7, 12, (2) 29, 31
WR74995 25.70
G 4, 5
WR74922 48.26
G 6
WR74997 22.60
G 8
WR74920 21.80
G (2) 10, (4) 19, 22
WR74917 47.40
G 9, 11, (2) 19
WR75005 32.20
G 13
WR75004 32.20
G 14
WR74918 37.40
G 15
WR75002 32.20
G 16
WR74999 30.00
G 17
WR74919 119.20
G 23, 24, 25, 26, 27, 28, (2) 29,
(2) 30, 31, 33, (6) 33, 34, 35, 36
WR74921 37.20
G 35, 37
WR74923 53.50
G 24, 25, 26, 27, 28, 31
WR74926 42.90
G 15, 30, 34
WR74930 21.50
G (2) 20, (6) 21
WR74916 16.80
G 22
WARN WINCH PARTS BREAKDOWN
