ATV / UTV U-JOINTS
Built to Exceed OEM Specifications
Includes: Spider, 4 Bearings, 4 Circlips and Grease Zerk
LOCATION REFERENCE NUMBER
PART #
D W TYPE
132480 24.95
L 25mm 43.6mm 1
132482 20.95
L 22mm 36mm 1
132484 20.95
L 20mm 41.25mm 1
132486 21.95
L 24mm 40.25mm 1
132488 20.95
L 0.94"
1.54"
1
132490 25.95
L 25mm 64.2mm 2
132492 20.95
L 20mm 33mm 1
132494 20.95
L 22mm 55mm 2
132496 21.95
L 25mm 45mm 1
132498 21.95
L 16mm 27.6mm 1
132500 21.97
L 1"
2.38"
1
132502 21.97
L 27mm 47.2mm 1
132509 21.95
L 0.84"
1.9"
2
U-JOINT LOCATION ON ATV
ENG MODEL NO
YEAR
(1)
FRONT
AXLE
INNER
(2)
FRONT
DRIVE-
SHAFT
DIFF
SIDE
(3)
FRONT
DRIVE-
SHAFT
ENGINE
SIDE
(4)
REAR
DRIVE-
SHAFT
ENGINE
SIDE
(5)
REAR
DRIVE-
SHAFT
DIFF
SIDE
(6)
REAR
AXLE
INNER
(7)
REAR
AXLE
OUTER
ARCTIC CAT ATV
250 250 4x4
2001 - 05
-----
-----
132480
-----
-----
-----
-----
300 300 4x4
1998 - 05
-----
-----
132480
-----
-----
-----
-----
375 375 4x4 w/AT
2002
-----
-----
132484
-----
-----
-----
-----
400 400 4x4
1998 - 00
-----
-----
132480
-----
-----
-----
-----
400 400 4x4 w/AT
2003 - 04
-----
-----
132484
-----
-----
-----
-----
400 400 4x4 w/MT
2001
-----
132480 132480
-----
-----
-----
-----
400 400 4x4 w/MT
2002
-----
-----
132480
-----
-----
-----
-----
400 400 4x4 w/MT
2003 - 04
-----
-----
132484
-----
-----
-----
-----
400 400 FIS 4x4 TRV
2009 - 13
-----
-----
132484
-----
-----
-----
-----
400 400 FIS 4x4 w/AT
2003 - 08
-----
-----
132484
-----
-----
-----
-----
400 400 FIS 4x4 w/MT
2002
-----
-----
132480
-----
-----
-----
-----
400 400 FIS 4x4 w/MT
2003 - 08
-----
-----
132484
-----
-----
-----
-----
400 400 TBX 4x4
2004 - 06
-----
-----
132484
-----
-----
-----
-----
400 400 VP 4x4
2005 - 06
-----
-----
132484 132484
-----
-----
-----
450 450 H1
2010 - 11
-----
-----
132484
-----
-----
-----
-----
450 450i EFI
2012
-----
-----
132484
-----
-----
-----
-----
450 450i TRV EFI
2012
-----
-----
132484
-----
-----
-----
-----
450 450i TRV GT EFI
2012
-----
-----
132484
-----
-----
-----
-----
454 454 4x4
1996 - 98
-----
-----
132480
-----
-----
-----
-----
500 500 4x4
1998 - 99
-----
-----
132480
-----
-----
-----
-----
500 500 4x4 w/AT
2000 - 02
-----
132480 132480
-----
-----
-----
-----
500 500 4x4 w/MT
2000 - 01
-----
132480 132480
-----
-----
-----
-----
500 500 EFI 4x4 A/T
2013
-----
-----
132484
-----
-----
-----
-----
500 500 FIS 4x4 w/AT
2002
-----
-----
132480
-----
-----
-----
-----
500 500 FIS 4x4 w/AT
2003 - 09
-----
-----
132484
-----
-----
-----
-----
500 500 FIS 4x4 w/MT
2002
-----
-----
132480
-----
-----
-----
-----
500 500 FIS 4x4 w/MT
2003 - 09
-----
-----
132484
-----
-----
-----
-----
500 500 FIS TBX 4x4
2002
-----
-----
132480
-----
132480
-----
-----
500 500 FIS TBX 4x4
2003 - 06
-----
-----
132480
-----
-----
-----
-----
500 500 FIS TRV 4x4
2003 - 08
-----
-----
132484
-----
-----
-----
-----
500 500 TRV
2013
-----
-----
132484
-----
-----
-----
-----
