ALL BALLS ATV/UTV UNIVERSAL JOINTS continued
U-JOINT LOCATION ON ATV
ENG MODEL NO
YEAR
(1)
FRONT
AXLE
INNER
(2)
FRONT
DRIVE-
SHAFT
DIFF
SIDE
(3)
FRONT
DRIVE-
SHAFT
ENGINE
SIDE
(4)
REAR
DRIVE-
SHAFT
ENGINE
SIDE
(5)
REAR
DRIVE-
SHAFT
DIFF
SIDE
(6)
REAR
AXLE
INNER
(7)
REAR
AXLE
OUTER
ARCTIC CAT ATV CONTINUED
500 500 XT EFI
2013
-----
-----
132484
-----
-----
-----
-----
550 550 EFI 4X4
2012 - 13
-----
-----
132484
-----
-----
-----
-----
550 550 GT EFI 4X4
2012
-----
-----
132484
-----
-----
-----
-----
550 550 H1 FIS 4X4
2009 - 11
-----
-----
132484
-----
-----
-----
-----
550 550 TRV
2012 - 13
-----
-----
132484
-----
-----
-----
-----
550 550 TRV 4x4 w/AT
2009 - 11
-----
-----
132484
-----
-----
-----
-----
550 550 XT EFI 4X4
2013
-----
-----
132484
-----
-----
-----
-----
650 650 4x4 H1
2005 - 11
-----
-----
132484
-----
-----
-----
-----
650 650 4x4 H1 Mud Pro
2010 - 11
-----
-----
132484
-----
-----
-----
-----
650 650 4x4 w/AT V2
2004 - 06
-----
132484 132484 132480 132480
-----
-----
700 700 Diesel
2008 - 11
-----
132484
-----
-----
-----
-----
-----
700 700 EFI 4x4
2006 - 08
-----
132484 132484
-----
-----
-----
-----
700 700 EFI 4x4
2009 - 13
-----
-----
132484
-----
-----
-----
-----
700 700 EFI H1 MUDPRO
2009 - 11
-----
-----
132484
-----
-----
-----
-----
700 700 EFI H1 w/AT
2008 - 11
-----
-----
132484
-----
-----
-----
-----
700 700 GT EFI
2012
-----
-----
132484
-----
-----
-----
-----
700 700 H1 TRV
2008
-----
132484 132484
-----
-----
-----
-----
700 700 H1 TRV
2009 - 11
-----
-----
132484
-----
-----
-----
-----
700 700 LTD EFI
2013
-----
-----
132484
-----
-----
-----
-----
700 700 XT
2013
-----
132480 132480 132480 132480
-----
-----
700 700i Diesel EFI
2012 - 13
-----
132484
-----
-----
-----
-----
-----
700 700i EFI MUDPRO
2012 - 13
-----
-----
132484
-----
-----
-----
-----
700 700i TRV Cruiser EFI
2012
-----
-----
132484
-----
-----
-----
-----
700 700i TRV GT EFI
2012
-----
-----
132484
-----
-----
-----
-----
1000 1000 Cruiser
2012
-----
132480 132480 132480 132480
-----
-----
1000 1000 TRV GT
2012
-----
132480 132480 132480 132480
-----
-----
1000 1000 TRV LTD
2013
-----
132480 132480 132480 132480
-----
-----
1000 1000 XT
2013
-----
132480 132480 132480 132480
-----
-----
1000 1000i GT
2012
-----
132480 132480 132480 132480
-----
-----
1000 1000i LTD EFI MUDPRO
2012 - 13
-----
132480 132480 132480 132480
-----
-----
1000 H2 MUDPRO
2010 - 11
-----
132480 132480 132480 132480
-----
-----
1000 H2 THUNDERCAT
2008
-----
132484 132484 132480 132480
-----
-----
1000 H2 THUNDERCAT
2009 - 11
-----
132480 132480 132480 132480
-----
-----
ARCTIC CAT UTV
550 550 Prowler
2009
-----
-----
-----
132480 132480
-----
-----
650 650 Prowler
2007
-----
-----
-----
132480 132480
-----
-----
650 650 Prowler XT
2006
-----
132484 132484 132480 132480
-----
-----
650 650 Prowler XT
2007 - 09
-----
-----
-----
132480 132480
-----
-----
1000 1000 Prowler XTZ
2011 - 13
-----
132480 132480
-----
-----
-----
-----
1000 Prowler H2 1000 XTZ
2009
-----
132480 132480 132480 132480
-----
-----
1000 Prowler H2 1000 XTZ
2010 - 11
-----
132480 132480
-----
-----
-----
-----
CAN AM ATV
330 Outlander 330
2004 - 05
-----
-----
-----
132494 132494
-----
-----
400 Outlander 400
2003 - 12
-----
-----
-----
132494 132494
-----
-----
400 Outlander 400
2013 - 14
-----
-----
-----
132494 132490
-----
-----
500 Outlander 500
2007
-----
-----
-----
132490 132490
-----
-----
500 Outlander 500
2008 - 12
-----
-----
132494 132490 132490
-----
-----
500 Outlander 500
2013 - 14
-----
-----
-----
132490 132490
-----
-----
500 Outlander 500 Power Steering
2010 - 12
-----
-----
132494 132490 132490
-----
-----
500 Quest 500
2002 - 03
-----
132494 132494 132494
-----
-----
-----
500 Renegade 500
2008 - 12
-----
-----
132494 132490 132490
-----
-----
500 Renegade 500
2013 - 14
-----
-----
-----
132490 132490
-----
-----
500 Renegade 500 Power Steering
2012
-----
-----
132494 132490 132490
-----
-----
500 Traxter 500
1999 - 04
-----
132494 132494 132494
-----
-----
-----
500 Traxter 500
2005
-----
-----
-----
132494
-----
-----
-----
650 Outlander 650
2006 - 12
-----
-----
132494 132490 132490
-----
-----
650 Outlander 650
2013 - 14
-----
-----
-----
132490 132490
-----
-----
