ALL BALLS ATV/UTV UNIVERSAL JOINTS continued
U-JOINT LOCATION ON ATV
ENG MODEL NO
YEAR
(1)
FRONT
AXLE
INNER
(2)
FRONT
DRIVE-
SHAFT
DIFF
SIDE
(3)
FRONT
DRIVE-
SHAFT
ENGINE
SIDE
(4)
REAR
DRIVE-
SHAFT
ENGINE
SIDE
(5)
REAR
DRIVE-
SHAFT
DIFF
SIDE
(6)
REAR
AXLE
INNER
(7)
REAR
AXLE
OUTER
POLARIS ATV CONTINUED
500 Sportsman 500 EFI
2009 - 10
-----
132488 132488
-----
-----
-----
-----
500 Sportsman 500 X2
2006 - 09
-----
132488 132488
-----
-----
-----
-----
500 Sportsman Forest 500
2011 - 13
-----
132488 132488
-----
-----
-----
-----
500 Sportsman Forest Tractor 500
2011 - 12
-----
132488 132488
-----
-----
-----
-----
500 Sportsman Touring 500 EFI
2008 - 13
-----
132488 132488
-----
-----
-----
-----
500 Worker 500 4x4
1999 - 02
132494 132494 132494
-----
-----
-----
-----
500 Xplorer 500
1997
132488 132488 132488
-----
-----
132500 132502
550 Sportsman 550
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
550 Sportsman 550
2012 - 13
-----
132509 132509 132488 132488
-----
-----
550 Sportsman 550 EPS
2010
-----
132488 132488 132488 132488
-----
-----
550 Sportsman 550 EPS
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
550 Sportsman 550 EPS
2012 - 14
-----
132509 132509 132488 132488
-----
-----
550 Sportsman 550 X2
2010
-----
132488 132488 132488 132488
-----
-----
550 Sportsman 550 X2
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
550 Sportsman 550 X2
2012 - 14
-----
132509 132509 132488 132488
-----
-----
550 Sportsman Forest 550
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
550 Sportsman Forest 550
2012 - 14
-----
132509 132509 132488 132488
-----
-----
550 Sportsman Touring EPS 550
2010 - 11
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
550 Sportsman Touring EPS 550
2012 - 14
-----
132509 132509 132488 132488
-----
-----
550 XP 550
2009 - 10
-----
132488 132488 132488 132488
-----
-----
570 Sportsman 570
2014 - 15
-----
132488 132488
-----
-----
-----
-----
570 Sportsman 570 EFI EPS
2014 - 15
-----
132488 132488
-----
-----
-----
-----
570 Sportsman 570 EFI HD
2014 - 15
-----
132488 132488
-----
-----
-----
-----
570 Sportsman 570 Forest
2014 - 15
-----
132488 132488
-----
-----
-----
-----
570 Sportsman 570 Forest EFI APS 2014 - 15
-----
132488 132488
-----
-----
-----
-----
570 Sportsman 570 Touring EFI
2014 - 15
-----
132488 132488
-----
-----
-----
-----
600 Sportsman 600 4x4
2003 - 04
132488 132488 132488 132488 132488
-----
-----
600 Sportsman 600 4X4
2005
-----
132488 132488 132488 132488
-----
-----
700 Sportsman 700 4x4
2002 - 04
132488 132488 132488 132488 132488
-----
-----
700 Sportsman 700 4x4
2005 - 07
-----
132488 132488 132488 132488
-----
-----
700 Sportsman 700 EFI
2005 - 07
-----
132488 132488 132488 132488
-----
-----
700 Sportsman MV7
2005
-----
132488 132488 132488 132488
-----
-----
700 Sportsman X2 700 EFI
2008
-----
132488 132488
-----
-----
-----
-----
800 Sportsman 800 EFI
2005
-----
132488 132488
-----
-----
-----
-----
800 Sportsman 800 EFI
2006 - 10
-----
132488 132488 132488 132488
-----
-----
800 Sportsman 800 EFI
2011 - 13
-----
132488 132488
-----
-----
-----
-----
800 Sportsman Forest 800 EFI
2012 - 14
-----
132488 132488
-----
-----
-----
-----
800 Sportsman Touring 800 EFI
2008 - 09
-----
132488 132488
-----
-----
-----
-----
800 Sportsman X2 800 EFI
2007 - 09
-----
132488 132488
-----
-----
-----
-----
850 Scrambler HO/ EPS 850
2013 - 14
-----
132509 132509 132488 132488
-----
-----
850 Scrambler XP 850 HO EPS
2014 - 15
-----
132509 132509 132488 132488
-----
-----
850 Sportsman Forest 850
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
850 Sportsman Forest 850
2012 - 14
-----
132509 132509 132488 132488
-----
-----
850 Sportsman Touring EPS 850
2010
-----
132488 132488 132488 132488
-----
-----
850 Sportsman Touring EPS 850
2011
-----
SEE
NOTE A
SEE
NOTE A
132488 132488
-----
-----
