2015 ATV / UTV CATALOG
U-JOINT LOCATION ON ATV
ENG MODEL NO
YEAR
(1)
FRONT
AXLE
INNER
(2)
FRONT
DRIVE-
SHAFT
DIFF
SIDE
(3)
FRONT
DRIVE-
SHAFT
ENGINE
SIDE
(4)
REAR
DRIVE-
SHAFT
ENGINE
SIDE
(5)
REAR
DRIVE-
SHAFT
DIFF
SIDE
(6)
REAR
AXLE
INNER
(7)
REAR
AXLE
OUTER
POLARIS UTV CONTINUED
800 RANGER RZR S 800
2009 - 14
-----
132488 132488
-----
-----
-----
-----
800 RANGER XP 800
2012
-----
132488 132488
-----
-----
-----
-----
800 RZR 800
2008 - 13
-----
132488 132488
-----
-----
-----
-----
800 Sportsman 800 EFI 6x6
2009 - 13
-----
132488 132488 132488 132488
-----
-----
800 Sportsman Forest 800 6x6
2013
-----
132488 132488 132488 132488
-----
-----
900 Brutus HD
2013
-----
132488 132488 132488 132488
-----
-----
900 Ranger 4X4 900 Diesel CREW 2012 - 14
-----
132488 132488 132488 132488
-----
-----
900 Ranger 4x4 DIESEL 900
2011 - 14
-----
132488 132488 132488 132488
-----
-----
900 Ranger 900 XP
2013 - 14
-----
132488 132488 132488 132488
-----
-----
900 Ranger RZR 4 XP 900
2012 - 14
-----
132488 132488
-----
-----
-----
-----
900 Ranger RZR XP 900
2011 - 14
-----
132488 132488
-----
-----
-----
-----
900 RZR 4 XP JAGGED X
2013
-----
132488 132488
-----
-----
-----
-----
1000 RZR XP 1000
2014
-----
132488 132488
-----
-----
-----
-----
SUZUKI
250 LT-4WD 250
1987 - 98
-----
-----
132480
-----
-----
-----
-----
250 LT-F250 Ozark
2002 - 13
-----
-----
-----
132484
-----
-----
-----
250 LT-F250F (Except Ozark)
1999 - 02
-----
-----
132480 132484 132484
-----
-----
250 LT-F4WD 250
1997 - 98
-----
-----
132480
-----
-----
-----
-----
250 LT-Z250
2004 - 09
-----
-----
-----
132484
-----
-----
-----
300 LT-F300F King Quad
1999 - 00
-----
-----
132480
-----
-----
-----
-----
300 LT-F300F King Quad
2001 - 02
-----
-----
132484
-----
-----
-----
-----
300 LT-F4WDX King Quad 300
1991 - 98
-----
-----
132480
-----
-----
-----
-----
400 LT-A400 2WD King Quad
2008 - 09
-----
-----
-----
132484
-----
-----
-----
400 LT-A400 Eiger 2wd
2002 - 04
-----
-----
-----
132484
-----
-----
-----
400 LT-A400 Eiger 2wd
2007
-----
-----
-----
132484
-----
-----
-----
400 LT-A400F 4WD King Quad
2008 - 13
-----
132484 132484 132484
-----
-----
-----
400 LT-A400F Eiger 4wd
2002 - 07
-----
132484 132484 132484
-----
-----
-----
400 LT-F400 2WD King Quad
2008 - 09
-----
-----
-----
132484
-----
-----
-----
400 LT-F400 Eiger 2wd
2002 - 04
-----
-----
-----
132484
-----
-----
-----
400 LT-F400 Eiger 2wd
2007
-----
-----
-----
132484
-----
-----
-----
400 LT-F400F 4WD King Quad
2008 - 12
-----
132484 132484 132484
-----
-----
-----
400 LT-F400F Eiger 4wd
2002 - 07
-----
132484 132484 132484
-----
-----
-----
450 LTA-450 X King Quad
2007 - 10
-----
-----
-----
132480
-----
-----
-----
500 LT-A500F Quad Master Auto
2000
-----
132480 132480
-----
-----
-----
-----
500 LT-A500F Quad Master Auto
2001
-----
132484 132484 132484
-----
-----
-----
500 LT-A500F Vinson
2002 - 07
-----
132484 132484 132480
-----
-----
-----
500 LT-A500X
2009 - 13
-----
-----
132480
-----
-----
-----
-----
500 LT-A500XP POWER STEERING 2011 - 13
-----
-----
132480
-----
-----
-----
-----
500 LT-F500F
1998 - 00
-----
-----
-----
132480
-----
-----
-----
500 LT-F500F
2001
-----
-----
-----
132484
-----
-----
-----
500 LT-F500F
2002
-----
132484 132484 132484
-----
-----
-----
500 LT-F500F Vinson
2003 - 07
-----
132484 132484 132480
-----
-----
-----
700 LTA-700 X King Quad
2005 - 07
-----
-----
-----
132480
-----
-----
-----
700 LTV-700F Twin Peaks
2004 - 06
-----
-----
-----
132486
-----
-----
-----
750 LTA-750 X King Quad
2008 - 13
-----
-----
-----
132480
-----
-----
-----
750 LTA-750 XP King Quad Power
Steering
2011 - 13
-----
-----
-----
132480
-----
-----
-----
ALL BALLS ATV/UTV UNIVERSAL JOINTS continued
