BRAKE PARTS
150
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
857001
BREAKAWAY SWITCHES
Completely sealed breakaway switches to automatically set trailer brakes in case of accidental trailer
breakaway. Required by law in some states. Emergency use only, not to be used to lock brakes
when parked or stored.
852010
, and
852005
have reinforced nylon case, weldable metal tab, nylon
pin assembly and are rust and corrosion free.
852009
has all metal parts and a brass pin assembly. Clamshell packaged.
PART #
DESCRIPTION
852010
8.94
E Breakaway Switch w/48" wires w/Cable & Nylon Pin Assembly
852005
8.90
E Breakaway Switch w/48" wires w/Cable & Nylon Pin Assembly (for use with 1-3 axle trailers)
852009 23.47
E Breakaway Switch w/48" wires w/Cable & Brass Pin Assembly
852010A 6.66
E 48" Replacement Cable & Nylon Pin Assembly (for
852010
Switch)
852009A 11.48
E 48" Replacement Cable & Brass Pin Assembly (for
852009
Switch)
852009
852005
852010
BATTERY CHARGER
For all 12v battery systems with a 4 amp-hr minimum output.
851024
will return trailer breakaway
system batteries to their maximum potential.
PART #
DESCRIPTION
851024
9.55
E DC-to-DC Accelerated Battery Charging Device (ABCD)
851024
BATTERY POST ADAPTER
Battery Post Adapter for General Motors side post batteries. Allows stud for attaching accessories wires.
Sold as a pair. Clamshell packaged.
BATTERY ISOLATORS
Cadmium plated isolator with terminal nuts and lock-washers. 3 terminal isolator for metal
frame ground systems, 4 terminal has insulated ground terminal for use with fiberglass
or other non-conductive materials. Isolates starting battery, provides secondary battery
current for auxiliary power and full time charging of both batteries. Clamshell packaged.
PART #
DESCRIPTION
857000
32.54
E Battery Isolator - 3 Terminal
857001
30.56
E Battery Isolator - 4 Terminal
857000
CIRCUIT BREAKERS
Used in 6, 12, and 24v DC applications. Automotive,
R.V., air conditioners, battery chargers, any application
requiring over-current protection. Non-corrosive
molded cover eliminates grounding when operating
against a fault line. Includes mounting bracket and
installed nuts and washers. Clamshell packaged.
PART #
DESCRIPTION
857010 8.33
E 15 Amp Circuit Breaker
857011 9.72
E 20 Amp Circuit Breaker
857012 8.48
E 30 Amp Circuit Breaker
857013 8.61
E 40 Amp Circuit Breaker
857022 8.69
E 50 Amp Circuit Breaker
ELECTROTEK
®
NON CONDUCTIVE DIELECTRIC SILICONE COMPOUND
ElectroTek
®
is to be used for all electrical connections, where a dielectric compound is required to
prevent voltage loss from arcing and to protect contacts from corrosion. Suppresses radio frequency
interference, dissipates heat, insulates trailer wiring connectors and seals out moisture. Effective for
automotive, RV and marine electrical applications. Non-water soluble. 3 oz. tube. Clamshell packaged.
DIELECTRIC GREASE
Using dielectric grease on electrical connectors helps prevent corrosion and increases reliability.
Display packaged.
852010A
TRAILER ELECTRIC BREAKAWAY SYSTEMS & ACCESSORIES
PART #
DESCRIPTION
853194 16.77
E Side Post Adapters for General Motors
PART #
DESCRIPTION
857200 20.47
E 3 oz. tube ElectroTek
®
PART #
DESCRIPTION
LB11755 20.47
E 2 oz. tube dielectric grease
