165 / 334
BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
165
2016 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
QUICK REFERENCE BRAKE CONTROL WIRING GUIDE
SECOND VEHICLE
MOUNTING KIT
For Impulse
TM
and
BrakeForce
TM
brake
controls
ELECTRONIC BRAKE
CONTROL INSTALLATION KIT
Everything needed to install most brake controls!
• 20 zip ties
• 4 butt splices
• 1 ring connector
• 1 splice connector
• 1 20’ amp fuse/holder
• 15’ black wire - 12 gauge
• 15’ white wire - 12 gauge
• 25’ blue wire - 12 gauge
• 3’ red wire - 16 gauge
NOTE: Locate wires on vehicle by function only. Not all vehicles are listed below. Refer to product instructions.
PART #
647685 13.95
G
PART #
647275 33.00
G
APPLICATION
YEAR PART #
LAND ROVER
LR3
05-10
647715 14.05
G
LR4
10-11
647715 14.05
G
Range Rover
05-13
647715 14.05
G
LEXUS
GX460
10-13
647815 16.80
G
GX470
03-10
647815 16.80
G
LX 570
08-13
647815 16.80
G
LINCOLN
Aviator (w/ factory 4 flat)
03-05
647715 14.05
G
Aviator (w/ factory 7 blade)
03-05
647715 14.05
G
Mark LT
07-08
647715 14.05
G
MKT
10-11
647715 14.05
G
MKT
12-13
620402 22.95
G
Navigator
98-12
647715 14.05
G
Navigator
13-14
620403 22.95
G
MERCURY
Mountaineer
02-10
647715 14.05
G
APPLICATION
YEAR PART #
NISSAN
Armada
04-13
647635 16.80
G
Frontier Pickup
04-13
647635 16.80
G
NV Van
14
647635 16.80
G
Pathfinder
04-13
647635 16.80
G
Titan
04-13
647635 16.80
G
Xterra
04-13
647635 16.80
G
RAM
Ram 1500 (w/ tow pkg)
10-12
620405 22.95
G
Ram 1500 (w/ tow pkg)
13-14
620407 22.95
G
Ram Pickup 2500/3500 (w/ tow pkg)
10-12
620405 22.95
G
SATURN
Outlook
07-10
620404 22.95
G
TOYOTA
Land Cruiser
03-10
647815 16.80
G
4-Runner
03-11
647815 16.80
G
Sequoia (w/ tow pkg) (MT)
03-13
647815 16.80
G
Tacoma
05-13
647815 16.80
G
Tundra
03-12
647815 16.80
G
PLUG-IN SIMPLE!
®
BRAKE CONTROL CONNECTORS continued
