BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
167
2016 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
WHITEWIRES
Length
3-1/8
Width
2
Thickness
15/16
Fits or Replaces
AL-KO Kober 12 x 2 6K & 7K
WHITEWIRES
Length
2 1/16
Width
1 15/16
Thickness 3/4
Fits or Replaces
Dexter
12 x 1-1/2
(Prior to Mid 1988)
Dexter
7 x 1-1/4
(After April 1990)
MAGNET KITS
WHITEWIRES
Length
3-1/8
Width
2
Thickness 15-16
Fits or Replaces
Hayes
10 x 1-5/8
10 x 2-1/4
12 x 2
(All - Replaces in Pairs)
(All - After Late 1994)
GREENWIRES
Length
3-1/8
Width
2
Thickness 15/16
Fits or Replaces
Dexter
10 x 2-1/4
Hayes
10 x 2-1/4
(After Mid 1987)
Hayes
10 x 1-5/8
(After to Mid to 1987)
Trailer Pac 102
Tow Craft 1103-100-017
WHITEWIRES
Length
3-1/8
Width
2
Thickness 15-16
Fits or Replaces
Dexter
12 x 2
Hayes
12 x 2
(After late 1987)
Trailer Pac 103
Tow Craft 1103-100-018
BLACKWIRES
Length
3-1/8
Width
2
Thickness
15/16
Fits or Replaces
Dexter
12 x 2 - 7K Axles
YELLOWWIRES
Length
3-1/8
Width
2
Thickness
15/16
Fits or Replaces
Dexter
10 x 1-1/2
(After Mid 1988)
LIGHT GREEN
WIRES
Length
3-1/8
Width
2
Thickness
15/16
Fits or Replaces
AL-KO Kober 10 x 2-1/4
BEARING &
CUP SETS
CUP/CONE
PART #
L14276/L14125A
LM14125CC 11.15
L
L15245/L15123
LM15123CC 9.40
L
L25520/L25580
LM25580CC 14.85
L
L44610/L44643
LM44643CC 6.30
L
LM48510/LM48548
LM48548CC 10.25
L
LM67010/LM67048
LM67048CC 7.20
L
L68111/L68149
LM68149CC 7.45
L
L11910/L11949
LM11949CC 8.30
L
MAGNET IDENTIFICATION
MAGNETS CAN BE IDENTIFIED BY THE COLOR OF THEWIRE USED
Dexter 7" x 1-1/4"
The magnets are round. Prior to April 1990 they had yellow wires, after 1990 the magnet has white wires. Replacement of magnets will need
to be done in pairs and updated to the new magnet along with the lever. The early levers are weak and will bend and hang up as they wear.
Dexter 10" x 1-1/2"
The magnet wires for the early model round magnets are white and the late model oval magnets are yellow.
Hayes 10" x 1-5/8"
The magnet wires for the early model round magnets are red and the late model oval magnets are green.
AL-KO 10" x 2-1/4"
It will have light green wires.
Hayes 10" x 2-1/4"
The early model round will have red wires and the late model will have oval green wires.
Dexter 10" x 2-1/4"
It uses green wires.
Fayette 10" x 2-1/4"
The round magnets will have white wires (obsolete).
AL-KO 12" x 2"
It will have white wires.
Hayes 12" x 2"
The early model round magnet will have red wires, the late model will be an oval magnet with white wires.
Dexter 12" x 2"
It will have white wires.
Dexter Centerline 12" x 2"
The 4.5K axles will have red orange wires, the 6/7K axles will have red wires (obsolete for both sizes).
• Sold each
855101 39.98
A
855114 52.24
E
855118 43.15
E
855106 52.65
E
855113 46.30
E
855109 54.63
E
856106 49.21
E
855109 54.63
E
REPLACEMENT PARTS THAT DO NOT APPEAR
IN EXPLODED VIEW
855120
8.52
B
855407
6.54
E
855410
4.50
B
ADJUSTING SCREW SPRING
10 x 1-5/8 Hayes
10 x 1-1/2 Dexter
10 x 2-1/4 Hayes
10 x 2-1/4 Dexter
10 x 2-1/4 Fayette
12 x 2 Hayes
12 x 2 Dexter
12 x 2 Fayette
MAGNET RETAINING RING
10 x 1-5/8 Hayes
10 x 2-1/4 Hayes
(Old Style)
12 x 2 Hayes
(Old Style)
ADJUSTING
SLOT PLUG (CAPS)
ALL SYSTEMS
