169 / 334
BRAKE PARTS
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
169
2016 TRAILER CATALOG
tie downs
tools
chemicals
TRAILER
DEXTER 7" x 1-1/4"
PART #
REF # DESCRIPTION
N/A
1 Actuating Lever - R.H.
N/A
1 Actuating Lever - L.H.
855113***
46.30
E
2 Magnet Kit
855320
30.27
E
3 Return Spring
SOLD ONLY
AS A KIT
4 Hold Down Clips
5 Adjusting Screw Spring
6 Adjusting Screw Assembly
GS203025
1.35
L
7 Seal - BTR (each)
GCP10
1.98
L
9 Grease Cap (each)
N/A
8 Bearing Set - Inner & Outer LM44649, LM44610
TBK9
12.95
G 7,8,9 Bearing/Seal Kit
855002
51.11
E
10 Shoe and Lining Kit
***After 4-90 to accommodate lever revision
DEXTER 10" x 1-1/2"
* Prior to Mid 1988 ** After Mid 1988
PART #
REF # DESCRIPTION
N/A
1 Actuating Lever - R.H.
855231**
13.50
B
1A Actuating Lever - R.H.
N/A
1 Actuating Lever - L.H.
855232**
13.50
B
1A Actuating Lever - L.H.
855113*
46.30
E
2 Magnet Kit
855118*
43.15
E
2A Magnet Kit
855306
8.30
E
3 Return Spring Set (Axle Set)
N/A
4 Hold Down Kit (Axle Set)
855404
11.43
E
5,6 Adjusting Screw Kit (Spring & Screw Assembly)
855607
7.36
E
7 Grease Seal (each)
GCP10
1.98
L
10 Grease Cap (each)
LM67048CC
7.20
L
8 Bearing Set - Inner LM67048, LM67010
N/A
9 Bearing Set - Outer LM44649, LM44610
855009
75.91
E
11 Shoe and Lining Kit (Axle Set)
