VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
SUZUKI
CONTINUED
LTZ 400
FORGED
REPLICA
03-14 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11.3:1 90 89.97 400
901233 901640 901014 901683
LTZ 400
FORGED
REPLICA
03-14 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11.3:1 90 89.98 400
901234 901640 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +1mm makes 407cc. Kit
includes: Piston, rings, pin, clips
11.3:1 91 90.96 407
1
901249 901642 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +2mm makes 416cc. Kit
includes: Piston, rings, pin, clips
11.3:1 92 91.96 416
2
901250 901643 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +4mm makes 440cc. Kit
includes: Piston, rings, pin, clips
11.3:1 94 93.95 440
4
901445 901645 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +4mm makes 440cc. Kit
includes: Piston, rings, pin, clips
11.3:1 94 93.96 440
4
901446 901645 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +4mm makes 440cc. Kit
includes: Piston, rings, pin, clips
11.3:1 94 93.97 440
4
901447 901645 901014 901683
LTZ 400
FORGED BIG
BORE
03-14 Big Bore Piston kit; +4mm makes 440cc. Kit
includes: Piston, rings, pin, clips
11.3:1 94 93.98 440
4
901712 901645 901014 901683
LTZ 400
FORGED
HIGH COMP
03-14 High Compression Piston kit; 13.5:1. Kit includes:
Piston, rings, pin, clips
13.5:1 90 89.95 400
901469 901640 901014 901683
LTZ 400
FORGED
HIGH COMP
03-14 High Compression Piston kit; 13.5:1. Kit includes:
Piston, rings, pin, clips
13.5:1 90 89.96 400
901470 901640 901014 901683
LTZ 400
FORGED
HIGH COMP
03-14 High Compression Piston kit; 13.5:1. Kit includes:
Piston, rings, pin, clips
13.5:1 90 89.97 400
901471 901640 901014 901683
LTZ 400
FORGED
STROKER
03-14 Stroker Performance Piston kit; For use with Hot
Rods #4159. Std bore makes 430cc. Kit includes:
Piston, rings, pin, clips
11.3:1 90 89.94 430
901518 901640 901014 901683
LTZ 400
FORGED
STROKER
03-14 Stroker Big Bore Piston kit; For use with Hot Rods
#4159. +2mm Makes 450cc. Kit includes: Piston,
rings, pin, clips
11.3:1 92 91.96 450
2
901539 901644 901014 901683
YAMAHA
BANSHEE
350
CAST LONG
ROD
87-06 Top end piston set includes: pistons, rings, pins,
circlips, top end gaskets, and wrist pin bearings
when applicable. For use with Hot Rods +5mm long
rod crankshaft 4011 and Hot Rods +4mm stroker
crankshaft 4111. 2.5mm head gasket for use with
stroker crankshaft only
66.5 66.45 403 2.5
901755
BANSHEE
350
CAST LONG
ROD
87-06 Top end piston set includes: pistons, rings, pins,
circlips, top end gaskets, and wrist pin bearings
when applicable. For use with Hot Rods +5mm long
rod crankshaft 4011 and Hot Rods +4mm stroker
crankshaft 4111. 2.5mm head gasket for use with
stroker crankshaft only
66 65.95 397
2
901754
BANSHEE
350
CAST LONG
ROD
87-06 Top end piston set includes: pistons, rings, pins,
circlips, top end gaskets, and wrist pin bearings
when applicable. For use with Hot Rods +5mm long
rod crankshaft 4011 and Hot Rods +4mm stroker
crankshaft 4111. 2.5mm head gasket for use with
stroker crankshaft only
65.5 65.45 391 1.5
901753
BANSHEE
350
CAST LONG
ROD
87-06 Top end piston set includes: pistons, rings, pins,
circlips, top end gaskets, and wrist pin bearings
when applicable. For use with Hot Rods +5mm long
rod crankshaft 4011 and Hot Rods +4mm stroker
crankshaft 4111. 2.5mm head gasket for use with
stroker crankshaft only
65 64.95 385
1
901752
BANSHEE
350
CAST LONG
ROD
87-06 Top end piston set includes: pistons, rings, pins,
circlips, top end gaskets, and wrist pin bearings
when applicable. For use with Hot Rods +5mm long
rod crankshaft 4011 and Hot Rods +4mm stroker
crankshaft 4111. 2.5mm head gasket for use with
stroker crankshaft only
64.5 64.45 379 0.5
901751
BANSHEE
350
CAST
REPLICA
87-06 Top end piston set includes: pistons, rings, pin,
circlips, top end gaskets, and wrist pin bearings
when applicable.
STD 66 65.95 350
2
901749
