VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
SUZUKI
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95.5 95.47 450
903153
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95.5 95.46 450
903154
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
13:1 95.5 95.45 450
903155
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11.7:1 95.5 95.47 450
903156
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11.7:1 95.5 95.46 450
903157
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain
11.7:1 95.5 95.45 450
903158
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
13:1 95.5 95.47 450
901741
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
13:1 95.5 95.46 450
901740
LT-R 450
FORGED
HIGH COMP
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
13:1 95.5 95.45 450
901739
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.7:1 95.5 95.47 450
901738
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.7:1 95.5 95.46 450
901737
LT-R 450
FORGED
REPLICA
06-09 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.7:1 95.5 95.45 450
901736
LT-R 450
FORGED BIG
BORE
06-12 Big Bore Piston kit; +2.5mm makes 474cc. Kit
includes: Piston, rings, pin, clips
11.7:1 98 97.96 474 2.5
901426 901652 901699 901684
LT-R 450
FORGED BIG
BORE
06-12 Big Bore Piston kit; +2.5mm makes 474cc. Kit
includes: Piston, rings, pin, clips
11.7:1 98 97.97 474 2.5
901427 901652 901699 901684
LT-R 450
FORGED BIG
BORE
06-12 Big Bore Piston kit; +2.5mm makes 474cc. Kit
includes: Piston, rings, pin, clips
11.7:1 98 97.98 474 2.5
901428 901652 901699 901684
LT-R 450
FORGED
REPLICA
06-12 Replica Piston kit; 11.7:1 Kit includes: Piston, rings,
pin, clips
11.7:1 95.5 95.45 450
901442 901616 901665 901684
LT-R 450
FORGED
REPLICA
06-12 Replica Piston kit; 11.7:1 Kit includes: Piston, rings,
pin, clips
11.7:1 95.5 95.46 450
901443 901616 901665 901684
LT-R 450
FORGED
REPLICA
06-12 Replica Piston kit; 11.7:1 Kit includes: Piston, rings,
pin, clips
11.7:1 95.5 95.47 450
901444 901616 901665 901684
LT-R 450
FORGED
HIGH COMP
06-12 High Compression Piston kit; 13.0:1. Kit includes:
Piston, rings, pin, clips
13:1 95.5 95.45 450
901476 901616 901665 901684
LT-R 450
FORGED
HIGH COMP
06-12 High Compression Piston kit; 13.0:1. Kit includes:
Piston, rings, pin, clips
13:1 95.5 95.46 450
901477 901616 901665 901684
LT-R 450
FORGED
HIGH COMP
06-12 High Compression Piston kit; 13.0:1. Kit includes:
Piston, rings, pin, clips
13:1 95.5 95.47 450
901478 901616 901665 901684
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain.
11.3:1 90 89.98 400
903135
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain.
11.3:1 90 89.97 400
903136
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and cam chain.
11.3:1 90 89.96 400
903137
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.3:1 90 89.98 400
901692
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.3:1 90 89.97 400
901691
LTZ 400
FORGED
REPLICA
03-14 Top end piston kit includes: piston, rings, pins,
circlips, top end gaskets, and wrist pin bearing
when applicable.
11.3:1 90 89.96 400
901690
LTZ 400
FORGED
REPLICA
03-14 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11.3:1 90 89.96 400
901232 901640 901014 901683
