VERTEX PISTONS
Type
Version Year Description
Comp.
Ratio
Cyl
Bore
(mm)
Piston
Diam.
(mm)
Disp
Size
Over
STD
Top End
Piston
Kit
Part #
Piston
Kit
Part #
Repl
Ring(s)
Part #
Wrist
Pin
Part #
Circlip
Part #
KAWASAKI
CONTINUED
KFX 400
FORGED
STROKER
03-06 Stroker Big Bore Piston kit; For use with Hot Rods
#4159. +2mm Makes 450cc. Kit includes: Piston,
rings, pin, clips
11.3:1 92 91.96 450
2
901539 901644 901014 901683
KFX 450R FORGED
REPLICA
08-14 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
12.4:1 96 95.95 450
901454 901648 901670 901678
KFX 450R FORGED
HIGH COMP
08-14 High Compression Piston kit; 13.4:1. Kit includes:
Piston, rings, pin, clips
13.4:1 96 95.95 450
901455 901648 901670 901678
KTM
450 SX ATV FORGED
REPLICA
08-11 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
12.5:1 97 96.93 450
901350 901620 901668 901684
450 SX ATV FORGED
REPLICA
08-11 Replica Piston kit; 12.5:1 Kit includes: Piston, rings,
pin, clips
12.5:1 97 96.94 450
901713 901620 901668 901684
450 SX ATV FORGED
REPLICA
08-11 Replica Piston kit; 12.5:1 Kit includes: Piston, rings,
pin, clips
12.5:1 97 96.95 450
901351 901620 901668 901684
450 SX ATV FORGED
HIGH COMP
08-11 High Compression Piston kit; 13.2:1. Kit includes:
Piston, rings, in, clips
13.2:1 97 96.93 450
901352 901620 901668 901684
450 SX ATV FORGED
HIGH COMP
08-11 High Compression Piston kit; 13.2:1. Kit includes:
Piston, rings, in, clips
13.2:1 97 96.95 450
901353 901620 901668 901684
450 XC ATV FORGED
REPLICA
08-12 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11:1 89 88.94 450
901344 901612 901662 901683
450 XC ATV FORGED
REPLICA
08-12 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11:1 89 88.95 450
901345 901612 901662 901683
450 XC ATV FORGED
HIGH COMP
08-12 High Compression Piston kit; 12.0:1. Kit includes:
Piston, rings, pin, clips
12:1 89 88.94 450
901348 901612 901662 901683
450 XC ATV FORGED
HIGH COMP
08-12 High Compression Piston kit; 12.0:1. Kit includes:
Piston, rings, pin, clips
12:1 89 88.95 450
901349 901612 901662 901683
450 XC ATV FORGED
HIGH COMP
08-12 High Compression Piston kit; 13.0:1 kit includes:
Piston, rings, pin, clips
13:1 89 88.94 450
901475 901612 901671 901683
505 SX ATV FORGED
REPLICA
08-12 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
12.5:1 100 99.94 505
901386 901589 901656 901681
505 SX ATV FORGED
REPLICA
08-12 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
12.5:1 100 99.95 505
901714 901589 901656 901681
525 XC ATV FORGED
REPLICA
08-11 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11:1 95 94.93 510
901230 901614 901014 901683
525 XC ATV FORGED
REPLICA
08-11 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
11.0:1 95 94.94 510
901231 901614 901014 901683
525 XC ATV FORGED
HIGH COMP
08-12 High Compression Piston kit; 12.5:1. Kit includes:
Piston, rings, pin, clips
12.5:1 95 94.93 510
901247 901614 901014 901683
525 XC ATV FORGED
HIGH COMP
08-12 High Compression Piston kit; 12.5:1. Kit includes:
Piston, rings, pin, clips
12.5:1 95 94.94 510
901248 901614 901014 901683
POLARIS
SPORTSMAN
800
FORGED
REPLICA
05-10 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
10.2:1 80 79.95 760
0
901715 901733 901045 901673
SPORTSMAN
800
FORGED
REPLICA
05-10 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
10.2:1 80 79.96 760
0
901716 901733 901045 901673
SPORTSMAN
800
FORGED
REPLICA
05-10 Replica Piston kit; Kit includes: Piston, rings, pin,
clips
10.2:1 80 79.97 760
0
901717 901733 901045 901673
SPORTSMAN
800
FORGED
HIGH COMP
05-10 High Compression Piston kit; 12.0:1 kit includes:
Piston, rings, pin, clips
12:1 80 79.95 760
0
901718 901733 901045 901673
SPORTSMAN
800
FORGED
HIGH COMP
05-10 High Compression Piston kit; 12.0:1 kit includes:
Piston, rings, pin, clips
12:1 80 79.96 760
0
901719 901733 901045 901673
SPORTSMAN
800
FORGED
HIGH COMP
05-10 High Compression Piston kit; 12.0:1 kit includes:
Piston, rings, pin, clips
12:1 80 79.97 760
0
901720 901733 901045 901673
SPORTSMAN
800
FORGED BIG
BORE
05-10 Big Bore Piston kit; +2mm makes 800cc. Kit
includes: Piston, rings, pin, clips
10.2:1 82 81.95 800
2
901721 901734 901045 901673
SPORTSMAN
800
FORGED BIG
BORE
05-10 Big Bore Piston kit; +2mm Kit includes: Piston,
rings, pin, clips
10.2:1 82 81.96 800
2
901722 901734 901045 901673
SPORTSMAN
800
FORGED BIG
BORE
05-10 Big Bore Piston kit; +2mm Kit includes: Piston,
rings, pin, clips
10.2:1 82 81.97 800
2
901723 901734 901045 901673
