AXLES, HUBS & SPRINGS
24
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
• Spindle is turned from high-tensile, cold-rolled steel on automotive-quality CNC lathes
• Spindle must be properly welded to axle tube
• 1" spindle end
• Includes castle nut, washer and cotter pin
• Sold individually
TIE DOWN ENGINEERING SPINDLES
PART # MFG #
CAPACITY END
SIZE
LENGTH STUB
LENGTH
HUB
LENGTH
INNER
BEARING
SIZE OUTER
BEARING
SIZE STUB
STYLE
LR80055
80055
18.95
G 1250# 1-1/4" 8-1/2"
2-5/8"
3-7/16"
LM44643 1"
LM44643 1"
ROUND
LR80060
80060
18.95
G 1350# 1-1/4"
7"
2"
3-7/16"
LM44649 1-1/16" LM44649 1-1/16" ROUND
LR80235
80235
24.95
G 1750# 1-3/4"
8"
2-9/16"
3-1/4"
LM68149 1-3/8" LM44649 1-1/16" ROUND
RELIABLE SPINDLES
• Cotter pin, washer, and castle nut sold separately
• Sold each (bulk)
<
------
D
-----
>
CAPACITY
PER PAIR
END
SIZE
LENGTH STUB
LENGTH
HUB
LENGTH
INNER
BEARING
SIZE OUTER
BEARING
SIZE STUB
STYLE
COTTER
PIN
WASHER CASTLE
NUT
2500# 1-1/4" 8-1/2"
3-1/8"
3-3/8"
LM44643 1"
LM44643 1"
ROUND CP2
SWP1 ANT1
2700# 1-1/4" 8-1/2"
3-1/8"
3-3/8"
LM44649 1-1/16" LM44649 1-1/16" ROUND CP2
SWP1 ANT1
PART # MFG #
RL1250
S-1250
16.95
E
RL1350
S-1350
13.55
E
Sold in display packages with castle nut, washer, and cotter pin included.
PART # MFG #
CAPACITY
PER PAIR
END
SIZE
LENGTH STUB
LENGTH
HUB
LENGTH
INNER
BEARING
SIZE OUTER
BEARING
SIZE STUB
STYLE
RL2000
2000
27.95
G 2500# 1-1/4"
8-1/2"
3-3/4"
3-3/8"
LM44643 1"
LM44643 1"
ROUND
RL2001
2001
27.95
G 2700# 1-1/4"
8-1/2"
3-3/4"
3-3/8"
LM44649 1-1/16" LM44649 1-1/16" ROUND
