How to measure for u-bolts:
A = Rod width - threads per inch
B = Between leg length (inside thread)
C = Leg length
D = Thread length
LR86217
LR86205
TIE DOWN U-BOLTS
Pairs of U-bolts are packaged with nuts and washers. All U-bolts are zinc plated to prevent rust.
PART # MFG #
A
RODWIDTH
B
BETWEEN LEG
C
LEG LENGTH
D
THREAD LENGTH
SQUARE/
ROUND
NUTS/
WASHERS
U/M
LR83069
83069Z 3/8-16
3-1/8"
3"
1-3/4"
SQUARE NO EA
1.30
L
LR86209
3/8-16
3-1/8"
3"
1-3/4"
SQUARE YES PR
4.55
G
LR10978
10978Z 3/8-16
4-1/8"
3"
1-3/4"
SQUARE NO EA
1.40
G
LR86211
3/8-16
4-1/8"
3"
1-3/4"
SQUARE YES PR
4.75
G
LR83043
83043Z 3/8-16
1-5/8"
3-9/16"
1-3/4"
SQUARE NO EA
1.30
L
LR86219
3/8-16
1-5/8"
3-9/16"
1-3/4"
SQUARE YES PR
4.35
G
LR10975
10975Z 3/8-16
2-1/8"
4"
1-3/4"
SQUARE NO EA
1.40
G
LR86208
3/8-16
2-1/8"
4"
1-3/4"
SQUARE YES PR
4.75
G
LR10977
10977Z 3/8-16
3-1/8"
4"
1-3/4"
SQUARE NO EA
1.55
G
LR86210
3/8-16
3-1/8"
4"
1-3/4"
SQUARE YES PR
4.95
G
PART # MFG #
A
RODWIDTH
B
BETWEEN LEG
C
LEG LENGTH
D
THREAD LENGTH
SQUARE/
ROUND
NUTS/
WASHERS
U/M
LR10967
10967Z 3/8-16
1-3/4"
4-13/16"
1-3/4"
ROUND NO EA
1.60
G
LR86216
3/8-16
1-3/4"
4-13/16"
1-3/4"
ROUND YES PR
5.15
G
PART # MFG #
A
RODWIDTH
B
BETWEEN LEG
C
LEG LENGTH
D
THREAD LENGTH
SQUARE/
ROUND
NUTS/
WASHERS
U/M
LR83707
83707Z 7/16-14
2-1/16"
2-5/16"
1"
SQUARE NO EA
1.30
L
LR86228
7/16-14
2-1/16"
2-5/16"
1"
SQUARE YES PR
4.85
G
LR83704
83704Z 7/16-14
4-1/16"
2-13/16"
1-3/4"
SQUARE NO EA
1.80
L
LR86234
7/16-14
4-1/16"
2-13/16"
1-3/4"
SQUARE YES PR
5.80
G
LR83708
83708Z 7/16-14
3-1/16"
3-5/16"
1-3/4"
SQUARE NO EA
1.80
L
LR86230
7/16-14
3-1/16"
3-5/16"
1-3/4"
SQUARE YES PR
5.80
G
LR10989
10989Z 7/16-14
1-9/16"
3-9/16"
2"
SQUARE NO EA
1.65
G
LR86212
7/16-14
1-9/16"
3-9/16"
2"
SQUARE YES PR
5.45
G
LR84051
84051Z 7/16-14
2-1/16"
4-5/16"
2"
SQUARE NO EA
1.90
L
LR86229
7/16-14
2-1/16"
4-5/16"
2"
SQUARE YES PR
6.05
G
LR83703
83703Z 7/16-14
3-1/16"
4-5/16"
2"
SQUARE NO EA
2.05
L
LR86231
7/16-14
3-1/16"
4-5/16"
2"
SQUARE YES PR
6.35
G
