AXLES, HUBS & SPRINGS
32
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
PART # MFG #
A
RODWIDTH
B
BETWEEN LEG
C
LEG LENGTH
D
THREAD LENGTH
SQUARE/
ROUND
NUTS/
WASHERS
U/M
LR10981
10981Z 1/2-13
3-1/8"
3"
1-1/2"
SQUARE NO EA
1.95
G
LR86205
1/2-13
3-1/8"
3"
1-1/2"
SQUARE YES PR
6.55
G
LR10983
10983Z 1/2-13
4-1/8"
3"
2"
SQUARE NO EA
2.15
G
LR86207
1/2-13
4-1/8"
3"
2"
SQUARE YES PR
7.25
G
LR84430
84430Z 1/2-13
3-1/16"
3-13/16"
1-1/2"
SQUARE NO EA
2.25
L
LR86214
1/2-13
3-1/16"
3-13/16"
1-1/2"
SQUARE YES PR
7.15
G
LR84503
84503Z 1/2-13
2-1/8"
4"
2"
SQUARE NO EA
2.15
L
LR86204
1/2-13
2-1/8"
4"
2"
SQUARE YES PR
6.95
G
LR84470
84470Z 1/2-13
3-1/8"
4"
2"
SQUARE NO EA
2.35
L
LR86206
1/2-13
3-1/8"
4"
2"
SQUARE YES PR
7.35
G
LR10991
10991Z 1/2-13
1-9/16"
4-1/16"
2"
SQUARE NO EA
2.05
G
LR86213
1/2-13
1-9/16"
4-1/16"
2"
SQUARE YES PR
6.75
G
LR84406
84406Z 1/2-13
2-1/16"
4-13/16"
2"
SQUARE NO EA
2.45
L
LR86215
1/2-13
2-1/16"
4-13/16"
2"
SQUARE YES PR
7.55
G
PART # MFG #
A
RODWIDTH
B
BETWEEN LEG
C
LEG LENGTH
D
THREAD LENGTH
SQUARE/
ROUND
NUTS/
WASHERS
U/M
LR84751
84751Z 1/2-13
2-3/8"
5-3/8"
2"
ROUND NO EA
2.65
L
LR86217
1/2-13
2-3/8"
5-3/8"
2"
ROUND YES PR
8.05
G
LR84758
84758Z 1/2-13
3-1/16"
6-11/16"
2"
ROUND NO EA
3.25
L
LR86218
1/2-13
3-1/16"
6-11/16"
2"
ROUND YES PR
9.50
G
How to measure for u-bolts:
A = Rod width - threads per inch
B = Between leg length (inside thread)
C = Leg length
D = Thread length
LR86217
LR86205
TIE DOWN U-BOLTS continued
Pairs of U-bolts are packaged with nuts and washers. All U-bolts are zinc plated to prevent rust.
LOCK NUTS
PART #
MFG #
SIZE U/M
LR10627
10627
3/8"-16 EA
0.25
L
LR10654
10654
7/16"-14 EA
0.25
L
LR10645
10645
1/2"-13 EA
0.35
L
WASHERS
PART #
MFG #
SIZE U/M
LR10502
10502
3/8"
EA
0.20
L
LR10510
10510
7/16"
EA
0.25
L
LR10573
10573
1/2"
EA
0.25
L
