TRAILER
DOUBLE EYE SPRING
PART # MFG #
PER
SPRING
CAPACITY
# OF
LEAVES
UNLOADED
LENGTH
CENTER
EYE
TO
SPRING
BOLT (A)
SPRING
BOLT
TO
SPRING
END (B)
FREE
OPEN
(H)
SPRING
WIDTH
BUSHING
INCLUDED?
20" LONG
DES7020
UNA-168 700#
3
20.31"
11"
11"
3.38"
1-3/4"
YES
20.40
H
DES1020
UNA-169 1000#
3
20.38"
11"
11"
3.19"
1-3/4"
YES
20.95
G
25" LONG
DES1225
UNA-219 1250#
3
25.13"
13.29"
13.29"
3.18"
1-3/4"
YES
26.55
E
DES1525
UNA-212 1830#
4
25.13"
13.19"
13.19"
3.25"
1-3/4"
YES
34.10
E
DES2025
UNA-220 2000#
3
25.25"
13.25"
13.25"
3"
1-3/4"
YES
32.00
E
DES3025
UNA-221 3000#
4
25.13"
13.29"
13.29"
3.29"
1-3/4"
YES
40.30
E
26" LONG
DES1026
UNA-124 1000#
4
26"
14.07"
14.07"
4
1-3/4"
YES
32.35
E
DES2526
UNA-052 2500#
5
26"
14"
14"
4.25"
1-3/4"
YES
53.60
E
27" LONG
DES1027
UNA-141 1000#
3
27"
13.98"
13.98"
2.83"
1-3/4"
YES
35.25
H
DES1727
UNA-210 1750#
4
27"
13.98"
13.98"
2.75"
1-3/4"
YES
47.65
E
DES3027
UNA142 3000#
6
27"
14.14"
14.14"
3.25"
1-3/4"
YES
76.45
E
29.70" LONG
DES0630
UNA-035 650#
3
29.70"
15.63"
15.63"
4"
1-3/4"
USE LSB2
33.45
E
DES1130
UNA-036 1250#
5
29.70"
15.63"
15.63"
4"
1-3/4"
USE LSB2
53.50
D
DES1530
UNA-032 1500#
7
29.70"
15.63"
15.63"
4"
1-3/4"
USE LSB2
67.95
E
29.75" LONG
DES1230
UNA-224 1250#
3
29.75"
15.87"
15.87"
4.38"
1-3/4"
YES
45.20
E
