AXLES, HUBS & SPRINGS
27
2015 TRAILER CATALOG
tires &
wheels
axles, hubs
& springs
tongue
accessories
hitches
electrical
brake
parts
trailer
hardware
locks &
pins
towing &
loading
tie downs
tools
chemicals
TRAILER
PLASTIC SPRING BUSHINGS
PART # MFG # OUTSIDE
DIAMETER
INSIDE
DIAMETER
LENGTH STYLE U/M
LSB1 PE 227 11/16" 9/16" 1-3/4" 2 EA 0.80 J
LSB2 PE 225 7/8" 9/16" 1-3/4" 2 EA 1.15 J
LSB4 PE226 11/16" 1/2" 1-3/4" 2 EA 0.80 J
LSB5 PE224 7/8" 1/2" 1-3/4" 2 EA 1.15 J
LSB182 PE182 7/8" 1/2" 11/16" 1 EA 0.65 J
STYLE 2
STYLE 1
PART # MFG # LENGTH
(L)
HEIGHT
(H)
BUSHING
ID (D)
BUSHING
PART #
690990 13-10 6.06" 4" 9/16" (3) LSB1 10.40 G
690991 13-104 5.70" 2.03" 9/16" (3) LSB1 6.70 H
690992 E-1 7.75" 2.88" 9/16" (3) LSB1 10.40 G
324000 91356 6.13" 2.44" 9/16" (3) LSB1 9.95 G
324001 A2252CB34 7.75" 2.88" 9/16" (2)
3/4" (1)
LSB1
N/A
12.95 G
324002 458 6.25" 2.03" 9/16" (2)
3/4" (1)
LSB1
N/A
10.95 G
• Sold each
• With nylon bushing
EQUALIZERS
